EG 45-GMF/PC GN - Mounting base housing

Component housing, Lower housing part with metal foot catch, without vents, width: 45 mm, height: 75 mm, color: green (6021), cross connection: without bus connector, number of positions cross connector: not relevant

Product Code: 2764849

Partner cod.: 2764849

PHOENIX CONTACT

Product properties	Type: Lower housing part closed, housing cover necessary to complete the module Lower housing part with metal foot catch Product type: Enclosure bottom part Product family: EG G PC Number of positions: 16 Housing type: Component housing Ventilation openings present: no Housing series: EG
Dimensions	Dimensional drawing: https://dam-mdc.phoenixcontact.com/rendition/156443151564/fdd7f57abcbd3549ae1e3573c4fc7dee/-S204x204-FJPG Width: 45 mm Height: 75 mm PCB design PCB thickness: 1.4 mm ... 1.8 mm
Material specifications	Color: green (6021) Flammability rating according to UL 94: V0 Surface characteristics: untreated Housing material: Polycarbonate
Environmental and real-life conditions	Ambient conditions Degree of protection: IP20 Max. IP code to attain: IP20 Ambient temperature (operation): -40°C ... 105°C (depending on power dissipation) Ambient temperature (storage/transport): -40°C ... 70°C Ambient temperature (assembly): -5°C ... 100°C
PCB data	Thickness of the PCB: 1.4 mm ... 1.8 mm
Mounting	Mounting type: DIN rail mounting Mounting position: Vertical (horizontal DIN rail)
