Industrial Automation
CB PT BRIDGE - Bridge
![](https://www.technologybsa.com/wp-content/uploads/2023/08/copia.png)
![](https://www.technologybsa.com/wp-content/uploads/2023/08/copia.png)
Product properties | Type: Male Product type: Bridge Number of positions: 1 No. of channels: 1 |
Electrical properties | No. of channels: 1 General Rated voltage: 277 VAC 80 VDC Rated current IN: 16 A (maximum) |
Connection data | Connection method: Spade connection |
Dimensions | Width: 12.3 mm Height: 45 mm Depth: 52 mm |
Mechanical properties | Mechanical data Open side panel: No |
Environmental and real-life conditions | Ambient conditions Degree of protection: IP30 (Actuation area) Ambient temperature (operation): -30°C ... 60°C Ambient temperature (storage/transport): -40°C ... 80°C |
Mounting | Mounting type: on base element |
ECLASS | ECLASS-11.0: 27141140 ECLASS-12.0: 27141140 ECLASS-13.0: 27250303 |
ETIM | ETIM 9.0: EC000489 |
UNSPSC | UNSPSC 21.0: 39121400 |
