| Notes | General: Refer to the data sheet for the range in the download area. |
| Product properties | Product type: Filler plug Product family: ME MAX B Type: Filler plug for unoccupied terminal points Housing type: DIN rail housing Ventilation openings present: no Housing series: ME-MAX |
| Dimensions | Width: 20 mm Height: 21.6 mm Depth: 8.1 mm |
| Material specifications | Color: black (9005) Flammability rating according to UL 94: V0 CTI according to IEC 60112: 600 Surface characteristics: untreated Housing material: Polyamide |
| Environmental and real-life conditions | Ambient conditions Max. IP code to attain: IP20 Ambient temperature (operation): -40°C ... 105°C (depending on power dissipation) Ambient temperature (storage/transport): -40°C ... 55°C Ambient temperature (assembly): -5°C ... 100°C Relative humidity (storage/transport): 80 % |
| Mounting | Mounting type: Latching |
| Packaging specifications | Outer packaging type: Resealable bag |
| ECLASS | ECLASS-11.0: 27182702 ECLASS-13.0: 27190605 |
| ETIM | ETIM 8.0: EC001031 |
| UNSPSC | UNSPSC 21.0: 31261500 |
