PHOENIX CONTACT 2908320

Not available

UEGM-MSTB GY - Electronic housing

Electronic housing, for PCB insertion, with 12-pos. Combicon pin strip

Product Code: 2908320

Partner cod.: 2908320

PHOENIX CONTACT

Tecnichal data

Technical Specs

Download

Tecnichal data

Product properties	Type: Connection system integrated, housing closed Complete housing Product type: Complete housing Product family: UEGM-MSTB Number of positions: 12 Housing type: Complete housing Housing series: UEG
Dimensions	Dimensional drawing: https://dam-mdc.phoenixcontact.com/rendition/156443151564/16aa414eab7d8c4cb9f4c9950e54bb3a/-S204x204-FJPG Width: 25 mm Height NS 35/7,5: 90.5 mm Depth: 79 mm Length: 79 mm
Material specifications	Color: gray Flammability rating according to UL 94: V2 Surface characteristics: untreated Housing material: Polyamide
Environmental and real-life conditions	Ambient conditions Ambient temperature (operation): -40°C ... 105°C

Technical Specs

ECLASS	ECLASS-11.0: 27182702 ECLASS-13.0: 27190301
ETIM	ETIM 8.0: EC001031
UNSPSC	UNSPSC 21.0: 31261500

Download

PER SCARICARE I DOCUMENTI E' NECESSARIO EFFETTUARE L'ACCESSO AL SITO

Material_description_00001.pdf

Technical_drawing_40619.pdf

Technical_drawing_40620.pdf
