Product properties | Product type: Single relay Operating mode: 100% operating factor Mechanical service life: 1x 107 cycles Insulation characteristics Overvoltage category: III Pollution degree: 3 |
Electrical properties | Maximum power dissipation for nominal condition: 0.17 W Test voltage (Winding/contact): 4 kV AC (50Hz, 1min., winding/contact) |
Input data | Coil side Nominal input voltage UN: 24 VDC Input voltage range: 14.4 VDC ... 66 VDC Input voltage range in reference to UN: see diagram Drive and function: monostable Drive (polarity): non-polarized Typical input current at UN: 7 mA Typical response time: 5 ms Typical release time: 2.5 ms Coil resistance: 3390 é ±10% (at 20°C) |
Output data | Switching Contact switching type: 1changeover contact Type of switch contact: Single contact Contact material: AgSnO Maximum switching voltage: 250 V AC/DC Minimum switching voltage: 5 V (100 mA) Limiting continuous current: 6 A Maximum inrush current: 10 A (4 s) Min. switching current: 10 mA (12V) Interrupting rating (ohmic load) max.: 140 W (24VDC) 20 W (48VDC) 18 W (60VDC) 23 W (110VDC) 40 W (220VDC) 1500 VA (250VAC) Switching capacity: 2 A (24V (DC13)) 0.2 A (at 110 V, DC13) 0.1 A (at 220 V, DC13) 3 A (at 24 V, AC15) 3 A (at 120 V, AC15) 3 A (at 230 V, AC15) Motor load according to UL 508: 1/4HP, 240 - 277VAC (N/O contact) 1/6HP, 240 - 277VAC (N/C contact) |
Connection data | Connection method: Plug / solder connection |
Dimensions | Width: 5 mm Height: 28 mm Depth: 16 mm |
Environmental and real-life conditions | Ambient conditions Degree of protection: RT II Ambient temperature (operation): -40°C ... 85°C Ambient temperature (storage/transport): -40°C ... 85°C |
Approvals | Corrosive gas test Identification: ISA-S71.04. G3 Harsh Group EN60068-2-60 |
Standards and regulations | Standards/regulations: IEC 60664 EN50178 EN61810-1 |
Mounting | Mounting type: Plug-in mounting Assembly instructions: in rows with zero spacing Mounting position: any |
ECLASS | ECLASS-11.0: 27371601 ECLASS-12.0: 27371601 ECLASS-13.0: 27371601 |
ETIM | ETIM 9.0: EC001437 |
UNSPSC | UNSPSC 21.0: 39122300 |
