EMG 17-OV- 12DC/240AC/3 - Solid-state relay module
![](https://www.technologybsa.com/wp-content/uploads/2023/08/copia.png)
![](https://www.technologybsa.com/wp-content/uploads/2023/08/copia.png)
Notes | Utilization restriction EMC note: EMC: class A product, see manufacturer's declaration in the download area |
Product properties | Product type: Solid-state relay module Application: Output function Operating mode: 100% operating factor Insulation characteristics Insulation: Basic insulation Insulation characteristicsâ Insulation: Basic insulation Overvoltage category: III Pollution degree: 2 |
Electrical properties | Test voltage (Input/output): 3.5 kV AC (Input/output) |
Input data | Nominal input voltage UN: 12 VDC Input voltage range in reference to UN: 0.8 ... 1.2 Input voltage range: 9.6 VDC ... 14.4 VDC Switching threshold "0" signal in reference to UN: ⤠0.4 Switching threshold "1" signal in reference to UN: ⥠0.8 Typical input current at UN: 4.1 mA Typical response time: 10 ms Typical turn-off time: 10 ms Operating voltage display: Yellow LED Protective circuit: Reverse polarity protection; Polarity protection diode Surge protection; Varistor Transmission frequency: 25 Hz |
Output data | Contact switching type: 1 N/O contact Design of digital output: electronic Output nominal voltage: 240 VAC Output voltage range: 48 VAC ... 280 VAC (50Hz...60Hz) Limiting continuous current: 3 A (see derating curve) Min. load current: 50 mA Leakage current: 4 mA (in off state) Surge current: 160 A (t=10ms) Phase angle cos phi min: 0.5 Max. load value: 128 A2s (I2 x t where t = 10 ms) Peak offstate voltage: 600 V (Periodic peak reverse voltage) Voltage drop at max. limiting continuous current: ⤠1 V Output circuit: 2-conductor, floating Protective circuit: RC element; RC element Surge protection; Varistor |
Connection data | Input side Connection method: Screw connection Stripping length: 8 mm Screw thread: M3 Conductor cross section rigid: 0.2 mm² ... 4 mm² Conductor cross section flexible: 0.2 mm² ... 2.5 mm² Conductor cross section AWG: 24 ... 12 Output side Connection method: Screw connection Stripping length: 8 mm Screw thread: M3 Conductor cross section rigid: 0.2 mm² ... 4 mm² Conductor cross section flexible: 0.2 mm² ... 2.5 mm² Conductor cross section AWG: 24 ... 12 |
Dimensions | Width: 17.5 mm Height: 75 mm Depth: 102 mm |
Material specifications | Flammability rating according to UL 94: V0 |
Environmental and real-life conditions | Ambient conditions Degree of protection: IP20 Ambient temperature (operation): -20°C ... 60°C Ambient temperature (storage/transport): -20°C ... 70°C |
Standards and regulations | Standards/regulations: IEC 60664 EN50178 |
Mounting | Mounting type: DIN rail mounting Assembly instructions: in rows with zero spacing Mounting position: horizontal |
ECLASS | ECLASS-11.0: 27371604 ECLASS-12.0: 27371604 ECLASS-13.0: 27371604 |
ETIM | ETIM 9.0: EC001504 |
UNSPSC | UNSPSC 21.0: 39122300 |
