PHOENIX CONTACT 2959311

PHOENIX CONTACT 2959311

Not available

UM 45-SEK - Lateral element

Side element, with cable fixture, 6 mm wide, cables fixed with cable ties, these are not included in the scope of delivery.

Product Code: 2959311 Copia - Copy

Copia - Copy

Partner cod.: 2959311 Copia - Copy

Copia - Copy

PHOENIX CONTACT

Tecnichal data

Download

Tecnichal data

Product properties	Product type: Panel mounting base side part Product family: UM45 Type: Lateral element Housing type: Press-drawn section housings Housing series: UM
Dimensions	Dimensional drawing: https://dam-mdc.phoenixcontact.com/rendition/156443151564/14f08a267c94fc4982c36f5d7acd4845/-S204x204-FJPG Depth: 45 mm
Material specifications	Color: green (6021) Flammability rating according to UL 94: V0 Housing material: Polyamide
Environmental and real-life conditions	Ambient conditions Ambient temperature (operation): -40°C ... 105°C (depending on power dissipation)

Download

PER SCARICARE I DOCUMENTI E' NECESSARIO EFFETTUARE L'ACCESSO AL SITO

Material_description_00001.pdf

Technical_drawing_41327.pdf
