| Product properties | Product type: Support Number of positions: 1 |
| Electrical properties | Nominal current IN: 0 A |
| Dimensions | Dimensional drawing: https://dam-mdc.phoenixcontact.com/rendition/156443151564/c5a5041d4787554a95678793b9cd8c24/-S204x204-FJPG Width: 6.2 mm Height: 95.5 mm Depth on NS35/7,5: 28.7 mm Depth on NS35/15: 36.2 mm |
| Material specifications | Color: gray Material: PA Flammability rating according to UL 94: V0 Insulating material: PA |
| Environmental and real-life conditions | Ambient conditions Ambient temperature (operation): -60°C ... 105°C (max. short-term operating temperature RTI Elec.) Ambient temperature (storage/transport): -25°C ... 60°C (for a short time, not exceeding 24h, -60°C to +70°C) Ambient temperature (assembly): -5°C ... 70°C Ambient temperature (actuation): -5°C ... 70°C Permissible humidity (storage/transport): 30 % ... 70 % |
| Mounting | Mounting type: DIN rail mounting |
| ECLASS | ECLASS-11.0: 27400607 ECLASS-12.0: 27400607 ECLASS-13.0: 27400607 |
| ETIM | ETIM 9.0: EC001166 |
| UNSPSC | UNSPSC 21.0: 39121700 |
