3200933 PHOENIX CONTACT - Technology Bsa

Product properties	Product type: Cable end sleeve Conductor category: stranded conductors, class 2, 5, 6 / B, C, K, M
Connection data	Conductor connection Conductor cross section flexible max.: 0.5 mm² Conductor cross section AWG max.: 20 Stripping length: 11 mm
Dimensions	Dimensional drawing: https://dam-mdc.phoenixcontact.com/rendition/156443151564/60bb1aec21c98a4f8cd65cb45bf95577/-S204x204-FJPG Sleeve length: 8 mm Ferrule diameter: 1.5 mm Sleeve wall thickness: 0.15 mm Insulating collar thickness: 0.25 mm Inner dimensions of the insulating collar: 2.5 mm
Material specifications	Color: white Material: CU-DHP Flammability rating according to UL 94: HB Coating: tin-plated (galvanic) Components: free from silicone and halogen
Mechanical properties	Technical data Sleeve length: 8 mm
Environmental and real-life conditions	Ambient conditions Permanent temperature: 105°C (-40Ã°C no load / 0Ã°C dynamic load) Short-term temperature: 120°C
Standards and regulations	Design according to standard: DINÃ46228-4, ULÃ486F-F
