| Product properties | Product type: Test plug terminal block Number of positions: 1 Potentials: 1 Insulation characteristics Overvoltage category: III Degree of pollution: 3 |
| Electrical properties | Rated surge voltage: 6 kV |
| Connection data | Nominal cross section: 2.5 mm² Rated cross section AWG: 14 Level 1 Screw thread: M3 Tightening torque: 0.5 ... 0.6 Nm Stripping length: 7 mm Connection in acc. with standard: IEC 60947-7-1 Conductor cross section rigid: 0.5 mm² ... 2.5 mm² Cross section AWG: 20 ... 14 (converted acc. to IEC) Conductor cross section flexible: 0.5 mm² ... 2.5 mm² Conductor cross section, flexible [AWG]: 20 ... 14 (converted acc. to IEC) Conductor cross-section flexible (ferrule without plastic sleeve): 0.5 mm² ... 1.5 mm² Flexible conductor cross section (ferrule with plastic sleeve): 0.5 mm² ... 1.5 mm² Nominal current: 6 A Maximum load current: 8 A Nominal voltage: 250 V |
| Dimensions | Width: 6.2 mm Height: 39.3 mm Depth: 78.7 mm Length: 39.3 mm |
| Material specifications | Color: red Flammability rating according to UL 94: V0 Insulating material group: I Insulating material: PA Static insulating material application in cold: -60°C Temperature index of insulation material (DIN EN 60216-1 (VDE 0304-21)): 125°C Relative insulation material temperature index (Elec., UL 746 B): 125°C |
| Standards and regulations | Connection in acc. with standard: IEC 60947-7-1 |
| ECLASS | ECLASS-11.0: 27141126 ECLASS-12.0: 27141126 ECLASS-13.0: 27250304 |
| ETIM | ETIM 9.0: EC000902 |
| UNSPSC | UNSPSC 21.0: 39121400 |
