| Product properties | Product type: Device marking Marking Number of individual labels: 270 Number of individual labels per row: 9 Identification technology: Plotter |
| Mounting | Mounting type: adhesive |
| Material specifications | Adhesive: Acrylic Color: yellow Material: Polyester foil Flammability rating according to UL 94: V0 Base element material: Polyester foil Components: Silicone-free |
| Environmental and real-life conditions | Test for substances that would hinder coating with paint or varnish Result: Test passed UV resistance Specification: ISO4892-2:2013-03 (following) Result: Test passed Test duration: 96 h Wipe resistance of inscriptions Specification: DINEN61010-1 (VDE0411-1):2011-07 DINEN62208 (VDE0660-511):2012-06 (in parts) Testing in a condensation changing climate in the presence of sulfur dioxide Specification: DIN50018:2013-05 Result: Test passed Climate level: AHT 1.0 S Cycles: 2 Salt spray test Specification: DINEN60068-2-11:2000-02 Result: Test passed Ambient conditions Ambient temperature (operation): -40°C ... 80°C Recommended ambient temperature (storage/transport): 23°C Recommended humidity (storage/transport): 50 % (Storage in a dry and dark place in the original packaging is recommended) |
| Dimensions | Width: 20 mm Length: 8 mm |
| Notes | General: Can be labeled with CMS |
| ECLASS | ECLASS-11.0: 27281103 ECLASS-12.0: 27281103 ECLASS-13.0: 27281103 |
| ETIM | ETIM 9.0: EC001288 |
| UNSPSC | UNSPSC 21.0: 39131500 |
