ROCKWELL AUTOMATION 22D-D012N104
ROCKWELL AUTOMATION 22D-D012N104
ROCKWELL AUTOMATION 22D-D012N104
ROCKWELL AUTOMATION 22D-D012N104
ROCKWELL AUTOMATIONNot available

PowerFlex 40P- 5.5 kW (7.5 HP) AC Drive

PowerFlex 40P AC Drive, 480VAC, 3PH, 12 Amps, 7.5 HP,Frame Size C, Panel Mount IP20 (NEMA Type Open), Display w/ Reset Only, Without CE compliant filter, Standard
Product Code: 22D-D012N104
Partner cod.: 22D-D012N104
ROCKWELL AUTOMATION


Diminuisci la quantità
Aumenta la quantità
Tecnichal data
Technical Specs
Description
Download
Tecnichal data
Features
Internal RS-485 and Common Industrial Protocol (CIP) communication
4-digit display, 3 additional status indicators and scroll/reset button
Power ratings:
Optional Remote Human Interface Modules (HIM) or PC interface for programming
Fiber application-specific features
Speed control with and without encoder feedback
StepLogic® allows operation as an independent position controller
Optional IP30 NEMA/UL Type 1 conversion kit
Drive overload protection, ramp regulation, and flying start
Premier Integration with PowerFlex® AC drives uses the Logix control platform to simplify parameter and tag programming and reduces development time
V/Hz control, sensorless vector control, as well as process PID
Configuration and programming via integral LCD keypad, remote keypad, or software
Technical Specs
Specifications
Voltage Rating:480VAC, 3PH
Enclosure:Panel Mount IP20 (NEMA Type Open)
Base Drive Information
Input Voltage:480VAC, 3PH
Output Current:12 Amps
Enclosure Style:Panel Mount IP20 (NEMA Type Open)
Frame Size:Frame Size C
Installed Options
Human Interface Module Version:Display w/ Reset Only
EMC Filtering Options:Without CE compliant filter
Internal Communication Module:Standard
Description
AC Drive, 5.5 kW (7.5 HP), 480V AC Input, 3 PH, 50-60 Hz, 12 A Output, IP20, NEMA Open Type, Panel Mounting, With Brake IGBT, Frame C, 0.98PF, Integral Keypad And Led Display, RS485, Fixed Terminal Block Connections
