800FM-LF7MN5WX10 ROCKWELL AUTOMATION

800F PB, 22mm Momentary Push Button, Illuminated Flush, 1 N.O., 1 N.O., Standard, White, White LED, Clear, Integrated LED Module, Metal, 120VAC/DC (Incand), 120VAC(LED), Screw Contact Block, Metal Latch Mount, Standard Pack

800F Momentary Push Button - Metal, Illuminated, Flush, Clear, Integrated LED, Metal Latch Mount, 120V AC, White LED, 1 N.O. Contact(s), 0 N.C. Contact(s), Standard Standard Pack (Qty. 1)

Product Code: 800FM-LF7MN5WX10

Partner cod.: 800FM-LF7MN5WX10

ROCKWELL AUTOMATION

Suitable for illumination	Yes
Operator cap/button shape	Round
Illumination lamp type	White LED
Contact block type	Standard
Illumination module type	Integrated LED module
Operator cap/button material	Plastic
Contact block thermal current rating	10 A
Illumination module input voltage	120V AC (LED)
Contact block utilization category (AC)	A600, AC 15 - screw termination
Contact block utilization category (DC)	Q600, DC-13 - screw termination
Contact block operational voltage, max	600V (A600, Q600) - screw termination
Operator cap type	Illuminated flush
Hole diameter	22.5 mm
Latch material	Metal
Operator mechanical design life (cycles, min.)	1.0E7
Contact block durability	1.0E7
Contact block mounting style	Latch
Operator cap text/symbol	Optional
Illumination module termination wire range	#18...12 AWG (0.75...2.5 mm^2)
Operator function	22 mm momentary push button
Contact block termination tightening torque	6 - 8 lb - in / 0.7 - 0.9 N-m
Operator type	Push button
Enclosure compatibility	IP66, Type 4/13 (Round metal operator)
Contact block configuration	1 NO
Shock	100 G
Vibration	10 G
Contact block termination wire range	#18...12 AWG (0.75...2.5 mm^2)
Illumination module termination tightening torque	6 - 8 lb - in / 0.7 - 0.9 N-m
Operating temperature	-25 Ã°C
Humidity	Ã¢Ã¢°¤95% RH from 25...60 Ã°C (77...140 Ã°F)
Storage temperature	-40 Ã°C
Illumination module mounting style	Latch
Operator construction/material	Metal
Termination style	Screw contact block
Operator cap color (lens)	Clear
Certifications	UL,UR, CSA, CCC, CE
