ROCKWELL AUTOMATION 800T-FXQ24A

ROCKWELL AUTOMATION 800T-FXQ24A

ROCKWELL AUTOMATION 800T-FXQ24A

Not available

800T PB, 30mm Push-Pull Device, Maintained, Mushroom Head, No Twist Release, 24V AC/DC, 2-Position, Standard Mushroom Cap, No Legend on Cap, Amber, No Guards - on Terminals, Full Voltage Type, No Block in Position 1, Incandescent Lamp, No Block in Posit

30.5mm Type 4/13 2 Pos. PB-Illum., Push-Pull, Amber, Mushrm Hd, Incand., 24V AC/DC, No Contacts

Product Code: 800T-FXQ24A

Partner cod.: 800T-FXQ24A

ROCKWELL AUTOMATION

Tecnichal data

Tecnichal data

Suitable for illumination	Yes
Operator cap/button shape	Round
Illumination lamp type	Incandescent
Illumination module type	Full voltage
Operator cap/button material	Plastic with Aluminum spinover
Illumination module input voltage	24V AC/DC
Operator cap type	Mushroom Head
Hole diameter	30.5 mm
Type of electric connection	Screw connection
Terminations with finger safe covers	No
Operator mechanical design life (cycles, min.)	250000
Operator cap color	Amber
Operator cap/button size	40 mm
Enclosure compatibility (NEMA type)	1, 4, 12, 13
Operator cap text/symbol	N/A
Illumination module termination wire range	14 - 18 AWG (x2)
Operator function	2-Position
Operator type	Push-Pull Unit
Operator special function	Maintained
Contact block configuration	No contacts
Shock	25 G (contact fragility)/100 G (no damage)
Vibration	10 G maximum
Illumination module termination tightening torque	6 - 8 lb - in / 0.7 - 0.9 N-m
Humidity	50 %
Operating temperature	-25 Ã°C
Hazardous location rating	No
Storage temperature	-40 Ã°C
Operator construction/material	Metal
Certifications	ABS, CCC, CE, CSA, EAC, GOST, UL
