SICK 6037684
SICKAvailable

IN40-D0304K INDUCTIVE SAFETY SWITCH

Safety switches: IN4000 Standard
Product Code: 6037684
Partner cod.: 6037684
SICK


Diminuisci la quantità
Aumenta la quantità
Tecnichal data
Technical Specs
Tecnichal data
Features
Sensor principleInductive
Number of safe outputs1
Switching delay from state changeT2 + 20 ms
Housing diameterM18
Enable zone1 mm ... 4 mm
Safe switch off distance Sar10 mm
Actuation directions5
Active sensor surfaces1
Monitoring time minimum dwell time≥ 0.2 s
Safety-related parameters
Safety integrity levelSIL 3 (IEC 61508)
CategoryCategory 3 (EN ISO 13849)
Performance levelPL e (EN ISO 13849)
PFHD (mean probability of a dangerous failure per hour)1.0 x 10-8
TM (mission time)

10 years (EN ISO 13849)

20 years (EN ISO 13849)

TypeType 3 (EN ISO 14119)
Actuator coding levelUncoded (EN ISO 14119)
Classification in compliance with IEC/EN 60947-5-3PDF-M
Functions
Safe series connectionWith T-connector (without diagnostics)
Interfaces
Connection typePlug connector, M12, 4-pin
Coupling nut materialBrass, special coating
Display elementsLEDs
Power indication
Status display
Electrical data
Protection classIII (EN 50178)
Supply voltage Vs24 V DC (19.2 V DC ... 30 V DC)
Power consumption15 mA
Type of outputSemiconductor, pulsed
Mechanical data
DesignCylindrical
Housing diameterM18
Housing length90.5 mm
Thread length65 mm
Weight0.06 kg
Material
HousingSpecially coated brass (housing), PBT (cover)
Installation typeFlush
Ambient data
Enclosure ratingIP69K (IEC 60529)
Ambient operating temperature–25 °C ... +70 °C
Storage temperature–25 °C ... +70 °C
Vibration resistance10 Hz ... 55 Hz, 1 mm (EN 60947-5-3)
Shock resistance30 g, 11 ms (EN 60947-5-3)
Classifications
ECLASS 5.027272401
ECLASS 5.1.427272401
ECLASS 6.027272401
ECLASS 6.227272401
ECLASS 7.027272401
ECLASS 8.027272401
ECLASS 8.127272401
ECLASS 9.027272401
ECLASS 10.027272401
ECLASS 11.027272401
ECLASS 12.027274101
ETIM 5.0EC001818
ETIM 6.0EC001818
ETIM 7.0EC001818
ETIM 8.0EC001818
UNSPSC 16.090139122205
Technical Specs
Unit weight0.279 Kilograms
Net unit weight0.279 Kilograms
Unit volume936 Cubic Centimetres (cm³)
Measurements9.000*6.500*16.000
Country of originGermany
