SICK 6044035
SICK 6044035
SICKNot available

VSE180-2P32437

Photoelectric sensors: V180-2
Product Code: 6044035
Partner cod.: 6044035
SICK


Diminuisci la quantità
Aumenta la quantità
Tecnichal data
Technical Specs
Tecnichal data
Features
Functional principleThrough-beam photoelectric sensor
Dimensions (W x H x D)18 mm x 18 mm x 69.8 mm
Housing design (light emission)Cylindrical
Housing length69.8 mm
Thread diameter (housing)M18 x 1
Optical axisAxial
Sensing range max.0 m ... 28 m
Sensing range0 m ... 20 m
FocusApprox. 5°
Type of lightVisible red light
Light sourceLED
Light spot size (distance)Ø 1,100 mm (20 m)
Angle of dispersionApprox. 5°
Wave length645 nm
AdjustmentPotentiometer, 270° (Sensitivity)
Mechanics/electronics
Supply voltage10 V DC ... 30 V DC
Ripple± 10 %
Power consumption, sender20 mA
Power consumption, receiver15 mA
Switching outputPNP
Switching modeDark switching
Signal voltage PNP HIGH/LOWApprox. VS – 1.8 V / 0 V
Output current Imax.≤ 100 mA
Response time≤ 0.5 ms
Switching frequency1,000 Hz
Connection typeConnector M12, 3-pin
Circuit protection

Protection classIII
Weight36 g
Housing materialPlastic, PBT/PC
Optics materialPlastic, PMMA
Enclosure ratingIP67
Items suppliedFastening nuts (4 x)
Ambient operating temperature–25 °C ... +55 °C
Ambient temperature, storage–40 °C ... +70 °C
Safety-related parameters
MTTFD2,274 years
DCavg0 %
Classifications
eCl@ss 5.027270901
eCl@ss 5.1.427270901
eCl@ss 6.027270901
eCl@ss 6.227270901
eCl@ss 7.027270901
eCl@ss 8.027270901
eCl@ss 8.127270901
eCl@ss 9.027270901
eCl@ss 10.027270901
eCl@ss 11.027270901
eCl@ss 12.027270901
ETIM 5.0EC002716
ETIM 6.0EC002716
ETIM 7.0EC002716
ETIM 8.0EC002716
UNSPSC 16.090139121528
Technical Specs
Unit weight57.100 Grams
Net unit weight57.1 Grams
Unit volume262.5 Cubic Centimetres (cm³)
Measurements7.500*3.500*10.000
Country of originChina
