0800414 PHOENIX CONTACT - Technology Bsa

WMS 4,8 (15X9)R YE - Shrink sleeve

Shrink sleeve, Roll, yellow, unlabeled, can be labeled with: THERMOMARKE.300 (D)/600 (D), THERMOMARK ROLLMASTER 300/600, THERMOMARK ROLL X1, THERMOMARK ROLL, THERMOMARK ROLL 2.0, THERMOMARK W, THERMOMARK X1.2, perforated, mounting type: slide-on, cable diameter range: 1.6 ... 4.8 mm, lettering field size: 15x9mm, Number of individual labels: 1000

Cod. Articolo: 0800414

Cod. Fornitore: 0800414

PHOENIX CONTACT

Notes	General: For the THERMOMARK ROLL, THERMOMARK ROLL 2.0, THERMOMARK ROLLMASTER 300/600, and THERMOMARK E.300 (D)/E.600 (D) roll printers, this material can only be processed outside of the printer using the integrated material dispenser pack. The specified minimum wire diameter of the shrink sleeve refers to its use as a marking material and does not guarantee any insulation characteristics once shrunk. Ã Depending on the processed material batch, as well as the storage and processing conditions, the maximum insertable wire diameter may be reduced.
Product properties	Product type: Shrink sleeve Type: Shrink sleeve Marking Number of individual labels: 1000 Number of individual labels per row: 4 Identification technology: Thermal transfer for rolls
Dimensions	Width: 9 mm Length: 15 mm External dimensions Outside diameter: 1.6 mm ... 4.8 mm
Material specifications	RoHS compliant: yes Color: yellow Material: Polyolefine Base element material: polyolefine Components: halogen-free
Cable/line	External cable diameter: 1.6 mm ... 4.8 mm
Environmental and real-life conditions	Test for substances that would hinder coating with paint or varnish Result: Test passed Scratch test for the determining scratch resistance Specification: DINÃENÃISOÃ1518-1:2019-10 (following) Requirements: Ã¢Ã¢°¥Ã5ÃN Result: Test passed Tesafilm test Specification: DINÃENÃISOÃ2409:2013 (following) Result: Test passed UV resistance Specification: ISOÃ4892-2:2013-03 (following) Result: Test passed Test duration: 96 h Temperature resistance Specification: ANSI/ULÃ969-2018:03 (following) Test duration: 240 h Rating 125Ã°C (150Ã°C): Test passed Wipe resistance of inscriptions Specification: DINÃENÃ61010-1 (VDEÃ0411-01):2020-03 DINÃENÃ62208 (VDEÃ0660-511):2012-06 (in parts) ISOÃ175:2010 (following) Test duration: 168 h Diesel [CAS No. 68476-34-6]: Test passed IRM 901: Test passed IRM 902: Test passed Testing in a condensation changing climate in the presence of sulfur dioxide Specification: DINÃ50018:2013-05 Result: Test passed Climate level: AHT 1.0 S Cycles: 2 Salt spray test Specification: DINÃENÃ60068-2-11:2000-02 Result: Test passed Test duration: 96 h Ambient conditions Ambient temperature (operation): -55°C ... 125°C Recommended storage conditions: 23Ã°C/50Ã% relative humidity. Storage in a dry and dark place in the original packaging is recommended. Recommended ambient temperature (storage/transport): 23°C Recommended humidity (storage/transport): 50 % Shelf life: 5Ãyears
Standards and regulations	Wipe resistance: DINÃENÃ61010-1 (VDEÃ0411-1)
Mounting	Mounting type: slide-on
