| Mounting | Mounting type: Front mounting M8 x 0.5 Connection method: Individual wires |
| Product properties | Product type: Circular connectors (device side) Number of positions: 6 No. of cable outlets: 1 Coding: A Insulation characteristics Overvoltage category: II Degree of pollution: 3 |
| Material specifications | Flammability rating according to UL 94: HB Seal material: Viton Contact material: Cu alloy Contact surface material: Au Contact carrier material: PA 6.6 Material for screw connection: Brass, nickel-plated |
| Electrical properties | Nominal voltage UN: 30 VAC 30 VDC Nominal current IN: 1.5 A |
| Connection data | Conductor connection Connection method: Individual wires |
| Connector | Connection 1 Head design: Socket Head cable outlet: straight Head thread type: M8 |
| Cable/line | Cable type: PVC litz wire Cable cross section: 0.14 mm² Ambient temperature (operation): -40°C ... 85°C (cable, fixed installation) -25°C ... 85°C (Cable, flexible installation) |
| Environmental and real-life conditions | Ambient conditions Degree of protection: IP67 Ambient temperature (operation): -25°C ... 85°C (Plug / socket) -40°C ... 85°C (without mechanical actuation) -25°C ... 85°C (Cable, flexible installation) -40°C ... 85°C (cable, fixed installation) |
| Standards and regulations | M8 Standard designation: M8 connector Standards/specifications: IEC 61076-2-104 |
| ECLASS | ECLASS-11.0: 27440102 ECLASS-12.0: 27440116 ECLASS-13.0: 27440116 |
| ETIM | ETIM 8.0: EC002635 |
| UNSPSC | UNSPSC 21.0: 39121400 |
