| Product properties | Product type: Circular connectors (device side) Number of positions: 8 Shielded: yes |
| Material specifications | Outer sheath, material: PUR Conductor material: Bare Cu litz wires |
| Electrical properties | Transmission characteristics (category): Class D Wave impedance: 100 é |
| Cable/line | Cable type: Ethernet Cable structure: 4x2xAWG26/7; S/FTP External cable diameter: 6.40 mm Outer sheath, material: PUR External sheath, color: water blue RAL5021 Wire diameter incl. insulation: 1 mm Single wire, color: white-blue, white-orange, white-green, white-brown Cable cross section: 0.14 mm² Conductor material: Bare Cu litz wires Conductor structure signal line: 7x 0.16 mm AWG signal line: 26 Wave impedance: 100 é ±15% (at 1 ... 100 MHz) Smallest bending radius, fixed installation: min. 32 mm (cable, fixed installation) Smallest bending radius, movable installation: min. 32 mm (Cable, flexible installation) Ambient temperature (operation): -25°C ... 80°C (Cable, flexible installation) |
| Environmental and real-life conditions | Ambient conditions Ambient temperature (operation): Plug / socket -40°C ... 80°C (without mechanical actuation) -25°C ... 80°C (Cable, flexible installation) |
| ECLASS | ECLASS-11.0: 27440102 ECLASS-12.0: 27440116 ECLASS-13.0: 27440116 |
| ETIM | ETIM 8.0: EC002635 |
| UNSPSC | UNSPSC 21.0: 39121400 |
