| Product properties | Type: M12 Sensor type: Ethernet Number of positions: 8 Connection profile: M12 Number of slots: 1 Shielded: yes Cable outlet: straight Thread type: M12 Insulation characteristics Overvoltage category: III Degree of pollution: 2 |
| Electrical properties | Rated voltage (III/3): 72 V (DC) Rated surge voltage: 0.8 kV Rated current: 1.75 A Nominal voltage UN: 48 V Nominal current IN: 0.5 A Transmission medium: Copper Transmission characteristics (category): CAT6A Power transmission: PoE++ |
| Connection data | Connection technology Connection method: Coupling |
| Material specifications | Color: black Flammability rating according to UL 94: V0 Material of grip body: PA Contact material: Copper alloy Housing material: Plastic |
| Mechanical properties | Mechanical data Insertion/withdrawal cycles: ⥠100 |
| Environmental and real-life conditions | Ambient conditions Degree of protection: IP65 IP67 IP65/IP67 Ambient temperature (operation): -25°C ... 85°C Ambient temperature (storage/transport): -25°C ... 85°C |
| Mounting | Mounting type: Rear mounting Connection method: Coupling |
| ECLASS | ECLASS-11.0: 27440312 ECLASS-12.0: 27440312 ECLASS-13.0: 27440312 |
| ETIM | ETIM 9.0: EC002641 |
| UNSPSC | UNSPSC 21.0: 39121400 |
