1415297 PHOENIX CONTACT - Technology Bsa

SACC-DSI-M12MSL-4FE-M16XL/0,2 - Device connector, rear mounting

Device connector, rear mounting, Power, 5-position, Pin, straight, M12-Standard, coding: L, on free cable end, Rear mounting, M16 x 1.5, Individual wires, cable length: 0.2 m, 2.50 mm², PEX litz wire, Alternative product in accordance with RoHS II without Exemption6c (Pb<0.1%) item no.: 1239084

Cod. Articolo: 1415297

Cod. Fornitore: 1415297

PHOENIX CONTACT

Notes	General: Lock nut is included in the scope of delivery FE not connected to metal parts that can be touched, no protective function
Mounting	Mounting type: Rear mounting M16 x 1.5 With flat nut Assembly instructions: With flat nut Connection method: Individual wires
Product properties	Product type: Circular connectors (device side) Sensor type: Power Number of positions: 5 No. of cable outlets: 1 Shielded: no Coding: B Thread type: M12 Insulation characteristics Overvoltage category: II Degree of pollution: 3
Material specifications	Flammability rating according to UL 94: V0 Seal material: FKM Material of grip body: Zinc die-cast, nickel-plated Contact material: CuZn Contact surface material: Ni/Au Contact carrier material: PA 6.6 Material for screw connection: Zinc die-cast, nickel-plated Conductor material: Tin-plated Cu litz wires
Electrical properties	Rated voltage in acc. with IEC 61076-2-101: 63 V Rated surge voltage: 1.5 kV 1.5 kV AC/DC Nominal voltage U_N: 63 VDC Test voltage: 1.5 kV Test voltage Core/Core: 6 kV
Connection data	Conductor connection Connection method: Individual wires Contact connection type: Pin Conductor cross section: 2.5 mm² Tightening torque: 0.8 Nm 1.3 Nm
Mechanical properties	Mechanical data Insertion/withdrawal cycles: > 100
Connector	Connection 1 Head design: Pin Head cable outlet: straight Head thread type: M12 Head locking type: Standard Coding: L Connection 2 Head design: free cable end
Cable/line	Cable length: 0.2 m Cable type: PEX litz wire Signal type/category: Power Single wire, color: brown 1, white 2, blue 3, black 4, pink FE Cable cross section: 2.5 mm² Conductor material: Tin-plated Cu litz wires Material wire insulation: PE-X Test voltage Core/Core: 6 kV Halogen-free: according to IEC 60754-1 Flame resistance: in acc. with UL FT-2 Other resistance: Hydrolysis-resistant Ambient temperature (operation): -40°C ... 105°C (cable, fixed installation) -25°C ... 105°C (Cable, flexible installation)
Environmental and real-life conditions	Ambient conditions Degree of protection: IP65/IP67 Ambient temperature (operation): -25°C ... 85°C (Plug / socket) -40°C ... 85°C (without mechanical actuation) -25°C ... 105°C (Cable, flexible installation) -40°C ... 105°C (cable, fixed installation)
Standards and regulations	Flame resistance: in acc. with UL FT-2 Other resistance: Hydrolysis-resistant M12 Standard designation: M12 connector Standards/specifications: IEC 61076-2-101
