PHOENIX CONTACT 1416263
PHOENIX CONTACT 1416263
PHOENIX CONTACTNon disponibile

VS-OE-M12FSBP-93R-LI/2,0 - Device connector, rear mounting

Device connector, rear mounting, PROFINET CAT5 (100 Mbps) CAT5 (100 Mbps), 4-position halogen-free, green RAL 6018, shielded, Socket, straight, M12-SPEEDCON, coding: D, on free cable end, Rear mounting, Cable lug connection, cable length: 5 m, PROFINET, Alternative product in accordance with RoHS II without Exemption6c (Pb<0.1%) item no.: 1260715
Cod. Articolo: 1416263
Cod. Fornitore: 1416263
PHOENIX CONTACT


Diminuisci la quantità
Aumenta la quantità
Caratteristiche Tecniche
Specifiche
Download
Caratteristiche Tecniche
NotesGeneral: The electrical and mechanical data specified assume that the connector pair is correctly locked and mounted. If the connector is unlocked and if there is a danger of contamination, the connector must be sealed using a protective cap > IP54. Influences arising from litz wires, cables or PCB assembly must also be taken into consideration.
Product propertiesProduct type: Data cable preassembled
Sensor type: PROFINET
Number of positions: 4
Application: Data
No. of cable outlets: 1
Shielded: yes
Coding: D
Insulation characteristics
Overvoltage category: II
Degree of pollution: 3
InterfacesBus system: PROFINET
Signal type/category: PROFINET CAT5 (IEC 11801:2002), 100 Mbps
Electrical propertiesRated surge voltage: 2.5 kV
Contact resistance: ≤ 3 mΩ
Insulation resistance: ≥ 100 MΩ
Nominal voltage UN: 48 VAC
60 VDC
Nominal current IN: 4 A (Plug/socket in accordance with IEC 61076-2-101, cable technical data is to be observed)
Transmission medium: Copper
Transmission characteristics (category): CAT5 (IEC 11801:2002)
Mechanical propertiesMechanical data
Insertion/withdrawal cycles: ≥ 100
Material specificationsFlammability rating according to UL 94: V0
Seal material: FKM
Contact material: CuZn
Contact surface material: Ni/Au
Contact carrier material: PA 6.6
Material for screw connection: Brass, nickel-plated
Connection dataConnection technology
Connection method: Cable lug connection
Conductor connection
Contact connection type: Socket
Connection method: Cable lug connection
Tightening torque: 2 Nm ... 3 Nm (Installation-side)
ConnectorConnection 1
Head design: Socket
Head cable outlet: straight
Head thread type: M12
Head locking type: SPEEDCON
Coding: D
Connection 2
Head design: free cable end
Cable/lineCable length: 5 m
PROFINET robot CAT5[93R]
Dimensional drawing: https://dam-mdc.phoenixcontact.com/rendition/156443151564/332e7b7c0f61684089bb5f28ed260786/-S204x204-FJPG
Cable weight: 55 kg/km
UL AWM Style: 20233 (80°C/300 V)
Number of positions: 4
Shielded: yes
Cable type: PROFINET robot CAT5[93R]
Conductor structure: 1x4xAWG22/19, S/TQ
Signal runtime: 4.8 ns/m
Conductor structure signal line: 19x 0.15 mm
AWG signal line: 22
Conductor cross section: 4x 0.34 mm²
Wire diameter incl. insulation: 1.5 mm
External cable diameter: 6.5 mm ±0.2mm
Outer sheath, material: PUR
External sheath, color: green RAL 6018
Conductor material: Tin-plated Cu litz wires
Material wire insulation: Foamed PE
Single wire, color: white, yellow, blue, orange
Thickness, outer sheath: approx. 1 mm
Overall twist: Star quad
Optical shield covering: 85 %
Insulation resistance: ≥ 500 MΩ*km
Loop resistance: ≤ 120.00 Ω/km
Wave impedance: 100 Ω ±5Ω (at 100 MHz)
Nominal voltage, cable: 300 V
Test voltage Core/Core: 2000 V (50Hz, 1min.)
Test voltage Core/Shield: 2000 V (50Hz, 1min.)
Minimum bending radius, fixed installation: 5 x D
Torsion force: ± 180°/m
Torsion cycles: 1000000
Shield attenuation: 2.9 dB (with 1 MHz)
5 dB (at 4 МHz)
8.1 dB (at 10 MHz)
10.4 dB (at 16 MHz)
11.9 dB (at 20МHz)
15.5 dB (at 31.25МHz)
26.5 dB (at 62.5МHz)
41 dB (at 100 MHz)
Halogen-free: according to IEC 60754-1
Flame resistance: according to IEC 60332-1-2
Resistance to oil: in accordance with DINEN60811-2-1
Other resistance: UV resistant According to UL1581, Section 1200
Ambient temperature (operation): -40°C ... 80°C
Ambient temperature (installation): -20°C ... 60°C
Environmental and real-life conditionsAmbient conditions
Degree of protection: IP67 (When plugged in)
IP65 (When plugged in)
IP65/IP67
Ambient temperature (operation): -25°C ... 85°C (Plug / socket)
-40°C ... 85°C (without mechanical actuation)
Standards and regulationsM12
Standard designation: M12 connector
Standards/specifications: IEC 61076-2-101
Specifiche
ECLASSECLASS-11.0: 27060308
ECLASS-12.0: 27060308
ECLASS-13.0: 27060308
ETIMETIM 9.0: EC002599
UNSPSCUNSPSC 21.0: 26121600
