| Notes | General: The electrical and mechanical data specified assume that the connector pair is correctly locked and mounted. If the connector is unlocked and if there is a danger of contamination, the connector must be sealed using a protective cap > IP54. Influences arising from litz wires, cables or PCB assembly must also be taken into consideration. |
| Product properties | Product type: Contact insert Sensor type: Ethernet Number of positions: 8 Application: Data Shielded: yes Coding: X Insulation characteristics Overvoltage category: III Degree of pollution: 3 |
| Electrical properties | Rated surge voltage: 1.5 kV Contact resistance: ⤠5 mé Insulation resistance: > 100 Mé Nominal voltage UN: 50 VAC 60 VDC Nominal current IN: 0.5 A Transmission characteristics (category): CAT6A |
| Interfaces | Signal type/category: Ethernet CAT6A |
| Material specifications | Material: Zinc die-cast (nickel-plated) Flammability rating according to UL 94: V0 Contact material: CuZn Contact surface material: Ni/Au Contact carrier material: PPA |
| Connector | Connection 1 Head design: Socket Head cable outlet: straight Head thread type: M12 Coding: X |
| Cable/line | Signal type/category: Ethernet CAT6A |
| Mechanical properties | Mechanical data Insertion/withdrawal cycles: > 100 |
| Environmental and real-life conditions | Ambient conditions Degree of protection: IP67 (when plugged in) IP67, when plugged in Ambient temperature (operation): -40°C ... 85°C |
| Standards and regulations | M12 Standard designation: M12 connector Standards/specifications: IEC 61076-2-109 |
| Mounting | Mounting type: PCB mounting Connection method: THR solder connection |
| Packaging specifications | Delivery state: with assembly pad |
| ECLASS | ECLASS-11.0: 27440102 ECLASS-12.0: 27440116 ECLASS-13.0: 27440116 |
| ETIM | ETIM 8.0: EC002635 |
| UNSPSC | UNSPSC 21.0: 39121400 |
