| Product properties | Product type: Contact insert Number of positions: 3 Shielded: no Coding: A Insulation characteristics Overvoltage category: III Degree of pollution: 3 |
| Electrical properties | Contact resistance: ⤠3 mé Insulation resistance: ⥠100 Mé Nominal voltage UN: 60 V Nominal current IN: 4 A |
| Signaling | Status display: No Status display present: No |
| Material specifications | Flammability rating according to UL 94: HB Contact material: CuSn Contact surface material: Au Contact carrier material: PA 6.6 |
| Connector | Connection 1 Head design: Socket Head cable outlet: angled Head thread type: M8 Coding: A |
| Environmental and real-life conditions | Ambient conditions Ambient temperature (operation): -25°C ... 85°C |
| Mounting | Mounting type: PCB mounting Connection method: Solder pins |
| ECLASS | ECLASS-11.0: 27440102 ECLASS-12.0: 27440116 ECLASS-13.0: 27440116 |
| ETIM | ETIM 9.0: EC002635 |
| UNSPSC | UNSPSC 21.0: 39121400 |
