1442230 PHOENIX CONTACT - Technology Bsa

SACCBP-MS-12CON-M16/2,0-PVCSCO - Device connector, rear mounting

Device connector, rear mounting, Universal, 12-position, PVC/PVC, black RAL9005, shielded, Pin, straight, M12-SPEEDCON, coding: A, on free cable end, Rear mounting, M16 x 1.5, Cable connection, cable length: 2 m, 0.14 mm², PVC black, Alternative product in accordance with RoHS II without Exemption6c (Pb<0.1%) item no.: 1239768

Cod. Articolo: 1442230

Cod. Fornitore: 1442230

PHOENIX CONTACT

Notes	General: The electrical and mechanical data specified assume that the connector pair is correctly locked and mounted. If the connector is unlocked and if there is a danger of contamination, the connector must be sealed using a protective cap > IP54. Influences arising from litz wires, cables or PCB assembly must also be taken into consideration.
Mounting	Mounting type: Rear mounting M16 x 1.5 Thread with flat nut Assembly instructions: Thread with flat nut Connection method: Cable connection
Product properties	Product type: Circular connectors (device side) Sensor type: Universal Number of positions: 12 No. of cable outlets: 1 Shielded: yes Coding: A Thread type: M12 Insulation characteristics Overvoltage category: II Degree of pollution: 3
Material specifications	Flammability rating according to UL 94: V0 Seal material: FKM Contact material: CuZn Contact surface material: Au Contact carrier material: PA 6.6 Material for screw connection: Zinc die-cast, nickel-plated Outer sheath, material: PVC Conductor material: Tin-plated Cu litz wires
Electrical properties	Rated surge voltage: 0.8 kV Contact resistance: Ã¢¤ 3 mÃ© Insulation resistance: Ã¢¥ 100 MÃ© Nominal voltage U_N: 30 V Nominal current I_N: 1.5 A Max. conductor resistance: 142 Ã©/km
Connection data	Conductor connection Connection method: Cable connection Contact connection type: Pin Conductor cross section: 6x 2x 0.14 mm² Tightening torque: 3 Nm 4 Nm
Mechanical properties	Mechanical data Insertion/withdrawal cycles: > 100
Connector	Connection 1 Head design: Pin Head cable outlet: straight Head thread type: M12 Head locking type: SPEEDCON Coding: A Connection 2 Head design: free cable end
Cable/line	Cable length: 2 m Cable type: PVC black Short symbol: PVC Signal type/category: Universal External cable diameter: 7 mm ±0.03mm Outer sheath, material: PVC External sheath, color: black RAL9005 Wire diameter incl. insulation: 1 mm ±0.05 mm Single wire, color: white-brown, green-yellow, gray-pink, blue-red, black-violet, gray/pink-red/blue Cable cross section: 0.14 mm² Material, inner sheath: PVC Conductor material: Tin-plated Cu litz wires Conductor structure signal line: 18x 0.10 mm Material wire insulation: PVC Thickness, insulation: 0.21 mm Overall twist: Six pairs around the filler to the core Shielding: Tinned copper braided shield Optical shield covering: 85 % Nominal voltage, cable: 300 V Test voltage, cable: 1500 VAC Cable resistance: 142 Ã©/km (at 20°C) Smallest bending radius, fixed installation: 42 mm Smallest bending radius, movable installation: 105 mm Resistance to oil: in accordance with DINEN60811-404 Flame resistance: IEC 60332-1-2, IEC 60332-1, FT1, VW-1 Other resistance: Hydrolysis and microbe resistant as per VDE 0282 section 10 Ambient temperature (operation): -40°C ... 85°C (cable, fixed installation) -25°C ... 85°C (Cable, flexible installation)
Environmental and real-life conditions	Ambient conditions Degree of protection: IP67 (When plugged in) IP65 (When plugged in) IP65/IP67 Ambient temperature (operation): -25°C ... 85°C (Plug / socket) -40°C ... 85°C (without mechanical actuation) -25°C ... 85°C (Cable, flexible installation) -40°C ... 85°C (cable, fixed installation) Resistance to oil: in accordance with DINEN60811-404
Standards and regulations	Flame resistance: IEC 60332-1-2, IEC 60332-1, FT1, VW-1 Resistance to oil: in accordance with DINEN60811-404 Other resistance: Hydrolysis and microbe resistant as per VDE 0282 section 10 M12 Standard designation: M12 connector Standards/specifications: IEC 61076-2-101
