| Product properties | Type: D-SUB Female/Female Product type: Female insert Sensor type: Universal Number of positions: 15 Connection profile: D-SUB Shielded: no Cable outlet: straight Insulation characteristics Overvoltage category: III Degree of pollution: 2 |
| Electrical properties | Rated voltage (III/3): 125 V Rated surge voltage: 1 kV Rated current: 5 A Transmission medium: Copper Power transmission: Power |
| Connection data | Connection technology Connection method: Coupling |
| Dimensions | Dimensional drawing: https://dam-mdc.phoenixcontact.com/rendition/156443151564/515b13ba5ffe7a4aaa951c5ff4eff751/-S204x204-FJPG Width: 17.8 mm Height: 39.26 mm Length: 12.55 mm |
| Material specifications | Flammability rating according to UL 94: V0 Housing surface material: metal-plated Contact material: Copper alloy Contact surface material: Gold Contact carrier material: Polyester GF Housing material: Metal |
| Mechanical properties | Mechanical data Insertion/withdrawal cycles: ⥠200 |
| Environmental and real-life conditions | Ambient conditions Degree of protection: IP20 Ambient temperature (operation): -55°C ... 125°C |
| Mounting | Mounting type: Threads Connection method: Coupling |
| ECLASS | ECLASS-11.0: 27440223 ECLASS-12.0: 27440223 ECLASS-13.0: 27440223 |
| ETIM | ETIM 9.0: EC003557 |
| UNSPSC | UNSPSC 21.0: 39121400 |
