| Product properties | Type: RJ45 Socket Product type: Female insert Sensor type: Ethernet Number of positions: 8 Connection profile: RJ45 Number of slots: 1 Shielded: yes Insulation characteristics Overvoltage category: I Degree of pollution: 1 |
| Electrical properties | Rated voltage (III/3): 72 V (DC) Rated surge voltage: ⥠1 kV Rated current: 1 A Insulation resistance: ⥠500 Mé Nominal voltage UN: 48 V Nominal current IN: 1 A Transmission medium: Copper Transmission characteristics (category): CAT5 |
| Connection data | Connection technology Connection method: IDC connection |
| Dimensions | Width: 22.8 mm Height: 16.8 mm Length: 41.6 mm |
| Material specifications | Flammability rating according to UL 94: V0 Housing surface material: metal-plated Contact material: Copper alloy Contact surface material: Gold Contact carrier material: PC Housing material: Metal |
| Mechanical properties | Mechanical data Insertion/withdrawal cycles: ⥠750 |
| Environmental and real-life conditions | Ambient conditions Degree of protection: IP20 Ambient temperature (operation): -20°C ... 70°C Ambient temperature (storage/transport): -40°C ... 70°C Ambient temperature (assembly): 0°C ... 60°C |
| Mounting | Mounting type: Snap in Connection method: IDC connection |
| ECLASS | ECLASS-11.0: 27440223 ECLASS-12.0: 27440223 ECLASS-13.0: 27440223 |
| ETIM | ETIM 9.0: EC003557 |
| UNSPSC | UNSPSC 21.0: 39121400 |
