| Product properties | Type: D-SUB Male Product type: Data connector (cable side) Sensor type: INTERBUS Number of positions: 9 Connection profile: D-SUB Application: INTERBUS No. of cable outlets: 2 Shielded: yes Cable outlet: angled Insulation characteristics Overvoltage category: II Degree of pollution: 2 |
| Electrical properties | Rated voltage (III/3): 63 V Rated surge voltage: 0.5 kV Rated current: 1 A Transmission medium: Copper |
| Connection data | Connection technology Connection method: Screw connection Connection cross section AWG: 26 ... 20 Conductor cross section: 0.14 mm² ... 0.5 mm² |
| Material specifications | Color: gray Flammability rating according to UL 94: V0 Cable seal material: CR/NBR Contact material: Copper alloy Contact surface material: Gold over nickel Contact carrier material: PBTP Housing material: Plastic |
| Cable/line | External cable diameter (): 5 mm ... 9 mm Cable cross section: 0.14 mm² |
| Mechanical properties | Mechanical data Insertion/withdrawal cycles: ⥠200 |
| Environmental and real-life conditions | Ambient conditions Degree of protection: IP20 Ambient temperature (operation): -20°C ... 70°C |
| Mounting | Connection method: Screw connection |
| ECLASS | ECLASS-11.0: 27440302 ECLASS-13.0: 27440302 ECLASS-12.0: 27440302 |
| ETIM | ETIM 9.0: EC001132 |
| UNSPSC | UNSPSC 21.0: 39121400 |
