MKDS 5 HV/ 2-9,52-Z - PCB terminal block

PCB terminal block, nominal current: 32 A, rated voltage (III/2): 1000 V, nominal cross section: 4 mm², number of potentials: 2, number of rows: 1, number of positions per row: 2, product range: MKDS 5 HV, pitch: 9.52 mm, connection method: Screw connection with tension sleeve, screw head form: L Slotted, mounting: Wave soldering, conductor/PCB connection direction: 0 °, color: green, Pin layout: Zigzag pinning M, Solder pin [P]: 5.2 mm, number of solder pins per potential: 1, type of packaging: packed in cardboard. The article can be aligned to create different nos. of positions! If used purely as 2-pos., we recommend version MKDSV 5 HV with anti-rotation pins.

Cod. Articolo: 1907432

Cod. Fornitore: 1907432

PHOENIX CONTACT

Product properties	Type: PC terminal block can be aligned Product line: COMBICON Terminals L Product type: Printed circuit board terminal Product family: MKDS 5 HV Number of positions: 2 Pitch: 9.52 mm Number of connections: 2 Number of rows: 1 Number of potentials: 2 Pin layout: Zigzag pinning M Solder pins per potential: 1
Electrical properties	Nominal current I_N: 32 A Nominal voltage U_N: 1000 V Degree of pollution: 3 Rated voltage (III/3): 690 V Rated surge voltage (III/3): 8 kV Rated voltage (III/2): 1000 V Rated surge voltage (III/2): 8 kV Rated voltage (II/2): 1000 V Rated surge voltage (II/2): 6 kV
Connection data	Connection technology Type: PC terminal block can be aligned Nominal cross section: 4 mm² Conductor connection Connection method: Screw connection with tension sleeve Conductor cross section rigid: 0.2 mm² ... 6 mm² Conductor cross section flexible: 0.2 mm² ... 4 mm² Conductor cross section AWG: 24 ... 10 Conductor cross section flexible, with ferrule without plastic sleeve: 0.25 mm² ... 4 mm² Conductor cross section, flexible, with ferrule, with plastic sleeve: 0.25 mm² ... 4 mm² 2 conductors with same cross section, solid: 0.2 mm² ... 1.5 mm² 2 conductors with same cross section, flexible: 0.2 mm² ... 1.5 mm² 2 conductors with same cross section, flexible, with ferrule without plastic sleeve: 0.25 mm² ... 0.75 mm² 2 conductors with the same cross section, flexible, with TWIN ferrule with plastic sleeve: 0.5 mm² ... 2.5 mm² Stripping length: 8 mm Tightening torque: 0.5 Nm ... 0.6 Nm
Mounting	Mounting type: Wave soldering Pin layout: Zigzag pinning M Drive form screw head: Slotted(L) Connection method: Screw connection with tension sleeve
Material specifications	Material data - contact Note: WEEE/RoHS-compliant, free of whiskers according to IEC 60068-2-82/JEDEC JESD 201 Contact material: Cu alloy Metal surface terminal point (top layer): Tin (5 - 7 µm Sn) Metal surface soldering area (top layer): Tin (5 - 7 µm Sn) Material data - housing Color (Housing): green (6021) Insulating material: PA Insulating material group: I CTI according to IEC 60112: 600 Flammability rating according to UL 94: V0 Glow wire flammability index GWFI according to EN60695-2-12: 850 Glow wire ignition temperature GWIT according to EN60695-2-13: 775 Temperature for the ball pressure test according to EN60695-10-2: 125 °C
Dimensions	Dimensional drawing: https://dam-mdc.phoenixcontact.com/rendition/156443151564/158b0afe23d1ab408f646eacfe25f655/-S204x204-FJPG Pitch: 9.52 mm Width [w]: 19.04 mm Height [h]: 26.7 mm Length [l]: 16 mm Installed height: 21.5 mm Solder pin length [P]: 5.2 mm Pin dimensions: 0.9 x 0.9 mm PCB design Hole diameter: 1.3 mm
Electrical tests	Air clearances and creepage distances \| Insulating material group: I Rated insulation voltage (III/3): 690 V Rated surge voltage (III/3): 8 kV Rated insulation voltage (III/2): 1000 V Rated surge voltage (III/2): 8 kV Rated insulation voltage (II/2): 1000 V Rated surge voltage (II/2): 6 kV
Packaging specifications	Type of packaging: packed in cardboard
