| Dimensions | Dimensional drawing: https://dam-mdc.phoenixcontact.com/rendition/156443151564/3f783436b27c3846a361ee861b282789/-S204x204-FJPG Width: 53.6 mm Height: 126.1 mm Depth: 54 mm Note on dimensions: Housing dimensions |
| Interfaces | AxiolineFlocal bus No. of channels: 1 Connection method: Bus base module |
| System properties | Module Input address area: 8 Byte Output address area: 8 Byte Required parameter data: 1 Byte Required configuration data: 7 Byte |
| Input data | Digital Input name: Digital inputs Description of the input: IEC 61131-2 type 3 Number of inputs: 4 (for 2-channel assignment) 8 (for 1-channel assignment) Cable length: max. 1000 m (200 m from the clock output to the safe input (total based on forward and return path)) Connection method: Push-in connection Connection technology: 2-, 3-, 4-conductor Input voltage: 24 VDC (via clock outputs T1 and T2 or external supply) Input voltage range: -3 VDC ... 30.2 VDC Nominal input voltage UIN: 24 VDC Nominal input current at UIN: typ. 4.2 mA Typical input current per channel: 4.2 mA Input filter time: 1.5 ms 3 ms (Default) 5 ms 15 ms |
| Product properties | Type: modular Product type: I/O component Product family: AxiolineF Application: Functional safety SafetyBridge technology |
| Electrical properties | Transmission medium: Copper Potentials Protective circuit: Protection against polarity reversal, EMC protective circuit, undervoltage detection Potentials: AxiolineF local bus supply (U Supply voltage: 5 VDC (via bus base module) Current draw: max. 310 mA typ. 280 mA (all inputs set; supply by UI of 19.2VDC...30VDC) Potentials: Supply for digital input modules (U Supply voltage: 24 VDC Supply voltage range: 19.2 VDC ... 30.2 VDC (including all tolerances, including ripple) Current draw: typ. 9 mA (all inputs set; supply from UI with 30VDC; without supply to the sensors via clock supplies T1 and T2) |
| Connection data | Connection technology Connection name: AxiolineF connector Conductor connection Connection method: Push-in connection Conductor cross section rigid: 0.2 mm² ... 1.5 mm² Conductor cross section flexible: 0.2 mm² ... 1.5 mm² Conductor cross section AWG: 24 ... 16 Stripping length: 8 mm AxiolineF connector Connection method: Push-in connection Conductor cross section, rigid: 0.2 mm² ... 1.5 mm² Conductor cross section, flexible: 0.2 mm² ... 1.5 mm² Conductor cross section AWG: 24 ... 16 Stripping length: 8 mm |
| Environmental and real-life conditions | Ambient conditions Ambient temperature (operation): -35°C ... 60°C (Mounting position: any) Degree of protection: IP20 Air pressure (operation): 70 kPa ... 108 kPa (up to 3000m above sea level) Air pressure (storage/transport): 66 kPa ... 108 kPa (up to 3500m above sea level) Ambient temperature (storage/transport): -40°C ... 85°C Permissible humidity (operation): 10 % ... 75 % (on average, 85% infrequently, non-condensing) Permissible humidity (storage/transport): 10 % ... 75 % (non-condensing) |
| Standards and regulations | Protection class: III (IEC 61140, EN61140, VDE0140-1) |
| Mounting | Mounting type: DIN rail mounting |
| ECLASS | ECLASS-11.0: 27242604 ECLASS-12.0: 27242604 ECLASS-13.0: 27242604 |
| ETIM | ETIM 9.0: EC001599 |
| UNSPSC | UNSPSC 21.0: 32151600 |
