| Product properties | Product type: Single relay Operating mode: 100% operating factor Mechanical service life: approx. 2x 107 cycles |
| Electrical properties | Maximum power dissipation for nominal condition: 0.12 W Test voltage (Winding/contact): 2 kV AC (50Hz, 1min., winding/contact) |
| Input data | Coil side Nominal input voltage UN: 24 VDC Input voltage range: 19.2 VDC ... 26.4 VDC (20°C) Drive and function: monostable Drive (polarity): non-polarized Typical input current at UN: 5 mA Typical response time: 5 ms Typical release time: 2 ms Coil resistance: 4800 é ±10% |
| Output data | Switching Contact switching type: 1 N/O contact Type of switch contact: Double contact Contact material: AgNi, hard gold-plated Maximum switching voltage: 250 VAC 125 VDC Minimum switching voltage: 5 VDC Limiting continuous current: 3 A Maximum inrush current: 5 A Min. switching current: 1 mA Interrupting rating (ohmic load) max.: 72 W (at 24 V DC) 60 W (at 48 V DC) 50 W (at 60 V DC) 50 W (at 110 V DC) 750 VA (for 230 V AC) |
| Dimensions | Width: 5 mm Height: 23 mm Depth: 17 mm |
| Environmental and real-life conditions | Ambient conditions Ambient temperature (operation): -40°C ... 85°C Ambient temperature (storage/transport): -40°C ... 85°C |
| Standards and regulations | Standards/regulations: DINVDE0110 IEC 255/DINVDE0435 (in relevant parts) |
| Mounting | Mounting position: any |
| ECLASS | ECLASS-11.0: 27371601 ECLASS-12.0: 27371601 ECLASS-13.0: 27371601 |
| ETIM | ETIM 8.0: EC001437 |
| UNSPSC | UNSPSC 21.0: 39122300 |
