| Number of contacts as normally open contact | 1 |
| Contact block configuration | 1 NO |
| Contact block type | Standard |
| Contact block utilization category (AC) | A600, AC 15 - screw termination |
| Contact block utilization category (DC) | Q600, DC-13 - screw termination |
| Contact block operational voltage, max | 600V (A600, Q600) - screw termination |
| Contact block thermal current rating | 10 A |
| Contact block mounting style | Latch |
| Termination style | Screw |
| Packaging | Standard pack (1 per package) |
| Latch material | Plastic / metal |
| Contact block termination wire range | #18...12 AWG (0.75...2.5 mm^2) |
| Vibration | 10 G |
| Shock | 100 G |
| Operator mounting hole dimension | 22.5 mm |
| Contact block durability | 1.0E7 |
| Contact block termination tightening torque | 6 - 8 lb - in / 0.7 - 0.9 N-m |
| Operating temperature | -25 °C |
| Storage temperature | -40 °C |
| Humidity | â¤95% RH from 25...60 °C (77...140 °F) |
| Certifications | UL,UR, CSA, CCC, CE |
