889N-F4GE-12F ROCKWELL AUTOMATION

Mini Cable, Female, Straight (Int Threads), Female, Straight (int threads), 4-Pins, Standard Materials, 4-Pins, Cable, No Connector, Cable - IEC Stndrd Color Code, No Connector, Same as First End, PVC Cbl, Grey, UnShld, 18AWG, Cable - IEC Stndrd Color

Cordset: Mini/Mini Plus, Female, Straight, 4-Pin, PVC Cable, Grey, Unshielded, IEC Color Coded, No Connector, 12 feet (3.66 meters), 18AWG

Cod. Articolo: 889N-F4GE-12F

Cod. Fornitore: 889N-F4GE-12F

ROCKWELL AUTOMATION

Number of poles	4
Operating temperature	-20 Ã°C
List of degrees of protection	IP67 and IP69K
Second end conductors	Same as first end
Enclosure type rating	NEMA 4, 6P, 12, 13, 1200 psi washdown
First end connector style	Female, straight (internal threads, except mini receptacles)
Cable type	PVC cable, grey, unshielded, 18 AWG
Material	Coupling nut: Epoxy-coated Zinc, housing: molded oil-resistant TPE, contact: Gold over Nickel-plated brass
Bend radius	10 x diameter
With shield connection	No
Cable length	3657.6 mm
Length	Connector: 61.8 mm
Special characteristic	Standard
Second end termination style	No connector
Second end termination type	Cable - IEC standard color code
Product type feature	Standard- Epoxy coated Zinc for DC micro, AC micro, mini QD with 2-6 pins, Standard-Nickel plated brass for pico, Standard-aluminum with clear sealant for mini QD with 7-12 pins
Diameter	2-pin cable: 6.0 mm, 3-pin cable: 6.6 mm, 4-pin cable: 6.6 mm, 5-pin cable: 7.6 mm, 6-pin cable: 8.1 mm
Material of contact surface	Gold
Material housing	Plastic
Type of plug-in contact, inner side	Female (bus)
Mounting method	Freely positionable
Assembly rating	4-pin: 300V, 7 A, 5-pin: 300V, 5.6 A, 6-pin: 300V, 5.6 A
Cable rating	UL PLTC AWM Style 2661VW-1 105C 300V, CSA AWM A/B 1/II 80C
