| Features | | Sub product family | microScan3 Pro - EtherCAT | | Model | Sensor including system plug (pre-mounted on the underside) | | Application | Indoor | | Protective field range | 4 m | | Warning field range | 40 m | | Number of simultaneously monitored fields | ≤ 8 | | Number of fields | 128 | | Number of monitoring cases | 128 | | Scanning angle | 275° | | Resolution (can be configured) | 30 mm 40 mm 50 mm 70 mm 150 mm 200 mm | | Angular resolution | 0.39° | | Response time | ≥ 95 ms | | Protective field supplement | 65 mm |
|
| Safety-related parameters | | Type | Type 3 (IEC 61496) | | Safety integrity level | SIL 2 (IEC 61508) | | Category | Category 3 (EN ISO 13849) | | Performance level | PL d (EN ISO 13849) | | PFHD (mean probability of a dangerous failure per hour) | 8.0 x 10-8 | | TM (mission time) | 20 years (EN ISO 13849) | | Safe state in the event of a fault | The safety outputs via the network are logic 0. |
|
| Functions | | Restart interlock | ✔ | | Multiple sampling | ✔ | | Monitoring case switching | ✔ | | Simultaneous monitoring | ✔ | | Static protective field switching | ✔ | | Safe contour detection | ✔ | | Contour as a reference | ✔ | | Integrated configuration memory | ✔ | | Measured data output | Via Ethernet |
|
| Interfaces | | Connection type | | | Voltage supply | 1 x male connector, M12, 4-pin, A-coded | | Data interface | 1 x M12 female connectors, 4-pin, D-coded | | Fieldbus, industrial network | 2 x M12 female connectors, 4-pin, D-coded |
| | Outputs | | | OSSD pairs | 0 | | Safety outputs via network | 8 |
| | Configuration method | PC with Safety Designer (Configuration and Diagnostic Software) | | Configuration and diagnostics interface | USB 2.0, Mini-USB, Ethernet |
| | Data interface | | | Type of data interface | Ethernet for data output, configuration and diagnostics (XF1, XF3) | | Port properties | 100Base-TX | | Auto-negotiation | | Auto-crossover (MDIX) | | Auto-polarity | | Services | Configuration and diagnostics using Safety Designer | | Data output | | Time synchronization via SNTP |
| | Fieldbus, industrial network | EtherCAT® | | Protocol | FSoE (Safety over EtherCAT®) | | Cycle time | ≥ 500 µs | | Port properties | XF1: EtherCAT IN | | XF2: EtherCAT OUT | | Diagnostics | Process data objects (PDOs) | | Service data objects (SDOs) | | Additional services | Ethernet over EtherCAT (EoE) for configuration and diagnostics using Safety Designer | | CAN application protocol over EtherCAT (CoE) |
| | Display elements | Graphic color display, LEDs |
|
| Electrical data | | Protection class | III (EN 61140) | | Supply voltage Vs | 24 V DC (16.8 V DC ... 30 V DC) | | Power consumption typical | 7.2 W |
|
| Mechanical data | | Dimensions (W x H x D) | 112 mm x 150.7 mm x 111.1 mm (without system plug) | | Weight | 1.45 kg | | Housing material | Aluminum | | Housing color | RAL 1021 (yellow), RAL 9005 (black) | | Optics cover material | Polycarbonate | | Optics cover surface finish | Outside with scratch-resistant coating |
|
| Ambient data | | Enclosure rating | IP65 (IEC 60529) | | Ambient light immunity | ≤ 3,000 lx (IEC 61496-3) |
| | Ambient operating temperature | –10 °C ... +50 °C | | Storage temperature | –25 °C ... +70 °C | | Vibration resistance | IEC 60068-2-6, IEC 60068-2-64, IEC 60721-3-5, IEC TR 60721-4-3, IEC 61496-1, IEC 61496-3 | | Class | 5M1 (IEC 60721-3-5) | | 3M4 (IEC TR 60721-4-3) |
| | Shock resistance | IEC 60068-2-27, IEC 60721-3-5, IEC TR 60721-4-3, IEC 61496-1, IEC 61496-3 | | Class | 5M1 (IEC 60721-3-5) | | 3M4 (IEC TR 60721-4-3) | | Continuous shock | 100 m/s², 16 ms | | 150 m/s², 6 ms |
| | EMC | IEC 61496-1, IEC 61000-6-2, IEC 61000-6-4 |
|
| Other information | | Type of light | Pulsed laser diode | | Wave length | 845 nm | | Detectable remission factor | 1.8% to several 1000% | | Laser class | 1M (21 CFR 1040.10 and 1040.11, IEC 60825-1) |
|
| Classifications | | ECLASS 5.0 | 27272705 | | ECLASS 5.1.4 | 27272705 | | ECLASS 6.0 | 27272705 | | ECLASS 6.2 | 27272705 | | ECLASS 7.0 | 27272705 | | ECLASS 8.0 | 27272705 | | ECLASS 8.1 | 27272705 | | ECLASS 9.0 | 27272705 | | ECLASS 10.0 | 27272705 | | ECLASS 11.0 | 27272705 | | ECLASS 12.0 | 27272705 | | ETIM 5.0 | EC002550 | | ETIM 6.0 | EC002550 | | ETIM 7.0 | EC002550 | | ETIM 8.0 | EC002550 | | UNSPSC 16.0901 | 39121528 |
|
