SICK 2061622
SICKNon disponibile

STL-2312-G01MAA3 CABLE STE 1M PACKED

Plug connectors and cables: Sensor/actuator cable
Cod. Articolo: 2061622
Cod. Fornitore: 2061622
SICK


Diminuisci la quantità
Aumenta la quantità
Caratteristiche Tecniche
Specifiche
Caratteristiche Tecniche
Technical specifications
Connection type head AFemale connector, JST, 8-pin, straight
Connection type head BMale connector, M23, 12-pin, straight
Cable1 m, 8-wire, PUR, halogen-free
Jacket materialPUR, halogen-free
Cable diameterØ 5.6 mm
Conductor cross section4 x 2 x 0.15 mm²
ShieldingShielded
Signal typeIncremental
DescriptionHead A: female connector, JST, 8-pin, straight Head B: male connector, M23, 12-pin, straight Cable: suitable for drag chain, PUR, halogen-free, shielded, 4 x 2 x 0.15 mm², Ø 5.6 mm
Classifications
ECLASS 5.019030312
ECLASS 5.1.419030312
ECLASS 6.027060304
ECLASS 6.227060304
ECLASS 7.027060304
ECLASS 8.027060304
ECLASS 8.127060304
ECLASS 9.027060304
ECLASS 10.027060304
ECLASS 11.027060304
ECLASS 12.027060304
ETIM 5.0EC000830
ETIM 6.0EC000830
ETIM 7.0EC003249
ETIM 8.0EC003249
UNSPSC 16.090126121604
Specifiche
Unit weight0.142 Kilograms
Net unit weight0.142 Kilograms
Unit volume504 Cubic Centimetres (cm³)
Measurements12.000*3.500*12.000
Country of originGermany
