SICK 6080599
SICKNon disponibile

SRA3-AAR150BKZI SAFERS3 SENSOR 5M

Safety radar sensors: safeRS/safeRS3
Cod. Articolo: 6080599
Cod. Fornitore: 6080599
SICK


Diminuisci la quantità
Aumenta la quantità
Caratteristiche Tecniche
Specifiche
Caratteristiche Tecniche
Features
ApplicationIndoor / Outdoor
ScopeStationary, mobile
Protective field range0.5 m ... 5 m
Number of protective fields4
Field of view

10° ... 100°, adjustable in 10° intervals (horizontal plane)

20° (vertical plane)

Response time≤ 100 ms
Vehicle speed≤ 2 m/s
Safety-related parameters
Safety integrity levelSIL 2 (IEC 62061)
CategoryCategory 3 (EN ISO 13849)
Performance levelPL d (EN ISO 13849)
PFHD (mean probability of a dangerous failure per hour)
Access protection1.66 x 10-8
MTTFD (mean time to dangerous failure)38 years (IEC 60050)
TM (mission time)20 years (EN ISO 13849)
Safe state in the event of a faultAt least one OSSD pair is in the OFF state.
Functions
Restart interlock
Muting
Manipulation protection
Safe detection of a person
Interfaces
Connection type
Voltage supply and signal transmissionMale connector, M12, 5-pin, A-coded
Female connector, M12, 5-pin, A-coded
Electrical data
Supply voltage Vs12 V DC, ± 20 %
Power consumption≤ 1 A
Power consumption≤ 4.7 W
Mechanical data
Dimensions (W x H x D)85 mm x 85 mm x 71 mm
Housing material
SensorPA 66
Rear viewAluminum
BracketPA 66, Glass fiber
Ambient data
Enclosure ratingIP67 (IEC 60529)
Ambient operating temperature–30 °C ... +60 °C
Storage temperature–40 °C ... +80 °C
Other information
Bandwidth60.6 GHz ... 62.8 GHz
Transmissin power≤ 16 dBm
Radio classClass 2 (2014/53/EU, RED - radio equipment)
Detection methodFMCW radar for motion detection
Items supplied

safeRS3 sensor

Two-axis/three-axis bracket

Safety instruction

Mounting instructions

Operating instructions for download

safeRS3 Designer (configuration and diagnostic software) for download

Classifications
ECLASS 5.027270890
ECLASS 5.1.427270890
ECLASS 6.027280800
ECLASS 6.227280800
ECLASS 7.027280890
ECLASS 8.027280890
ECLASS 8.127280890
ECLASS 9.027280890
ECLASS 10.027280890
ECLASS 11.027280890
ECLASS 12.027280890
ETIM 5.0EC001825
ETIM 6.0EC001825
ETIM 7.0EC001825
ETIM 8.0EC001825
UNSPSC 16.090139121528
Specifiche
Unit weight0.497 Kilograms
Net unit weight0.497 Kilograms
Unit volume3460.375 Cubic Centimetres (cm³)
Measurements15.500*9.500*23.500
Country of originItaly
