Product properties | Product type: Cable sleeve No. of conductors: 1 |
Dimensions | Dimensional drawing: https://dam-mdc.phoenixcontact.com/rendition/156443151564/d21d4436cba23641a516bac77cb715b4/-S204x204-FJPG Width: 19.5 mm Height: 17 mm Length: 29.5 mm |
Material specifications | Material: NBR |
Cable/line | External cable diameter (): 1x 7 mm ... 24 mm |
Characteristics | Seal size: large Design, Format: Round cable Design, Cable seal: closed |
Environmental and real-life conditions | Ambient conditions Degree of protection: IP54 IP65 Ambient temperature (operation): -40°C ... 125°C (static) |
Mounting | Assembly instructions: IP54: for vertical sealing frame mounting/for horizontal sealing frame mounting (downward cable outlet direction). IP65: vertical mounting/horizontal mounting (downward cable outlet direction) of the sealing frame directly on the housing panel and use of a 3.6mm wide cable binder (e.g., item 3240744). |
ECLASS | ECLASS-11.0: 27144425 ECLASS-12.0: 27144425 ECLASS-13.0: 27144425 |
ETIM | ETIM 9.0: EC000451 |
UNSPSC | UNSPSC 21.0: 39121400 |
