Industrial Automation
Product properties | Product type: System marking Area of application: Identification of emergency stop buttons according to ISO13850 Marking Number of individual labels: 1 Number of individual labels per row: 1 Printing: Blank Identification technology: Thermal transfer |
Dimensions | Width: 0 mm Height: 0 mm Depth: 0.09 mm Length: 0 mm Diameter: 90.00 mm Min. material thickness: 0.09 mm |
Material specifications | Color: yellow Material: PVC Components: Silicone-free |
Environmental and real-life conditions | Test for substances that would hinder coating with paint or varnish Result: Test passed Test for substances that would hinder coating with paint or varnishâ Result: Test passed Scratch test for the determining scratch resistance Specification: DINENISO1518-1:2019-10 (following) Requirements: â¥5N Result: Test passed Tesafilm test Specification: DINENISO2409:2013 (following) Result: Test passed UV resistance Specification: DINENISO4892-2:2021-11 (following) ISO175:2010 (following) Result: Test passed Test duration: 96 h 168 h Diesel [CAS No. 68476-34-6]: Test passed IRM 901: Test passed IRM 902: Test passed Testing in a condensation changing climate in the presence of sulfur dioxide Specification: DIN50018:2013-05 Result: Test passed Climate level: AHT 1.0 S Cycles: 2 Salt spray test Specification: DINEN60068-2-11:2000-02 Result: Test passed Test duration: 96 h Ambient conditions Ambient temperature (operation): -40°C ... 60°C Ambient temperature (assembly): > 10°C Recommended ambient temperature (storage/transport): 22°C Recommended humidity (storage/transport): 50 % ... 55 % (Storage in a dry and dark place in the original packaging is recommended) Shelf life: 2years |
Standards and regulations | Wipe resistance: DINEN61010-1 (VDE0411-1) |
Mounting | Mounting type: adhesive |
ECLASS | ECLASS-13.0: 40200202 ECLASS-11.0: 40200202 ECLASS-12.0: 40200202 |
ETIM | ETIM 9.0: EC001777 |
UNSPSC | UNSPSC 21.0: 55121700 |
