1084012 PHOENIX CONTACT - Technology Bsa

ICC20-H/4R3,5-7035 - PCB header

PCB headers, color: light grey, nominal current: 8 A, rated voltage (III/2): 150 V, contact surface: Tin, contact connection type: Pin, number of potentials: 4, number of rows: 1, number of positions: 4, number of connections: 4, product range: ICC..-H/..R3,5, pitch: 3.5 mm, mounting: Wave soldering, pin layout: Linear pinning, solder pin [P]: 3.65 mm, number of solder pins per potential: 1, Pin connector pattern alignment: Standard, locking: Snap-in locking, mounting: without, type of packaging: Box packaging, Product with pin output on right side

Product Code: 1084012

Partner cod.: 1084012

PHOENIX CONTACT

Product properties	Type: Header perpendicular to the PCB Product type: PCB headers Product family: ICC..-H/..R3,5 Number of positions: 4 Pitch: 3.5 mm Number of connections: 4 Number of rows: 1 Number of potentials: 4 Pin layout: Linear pinning Solder pins per potential: 1
Electrical properties	Nominal current I_N: 8 A Degree of pollution: 3 Contact resistance: 1.76 mÃ© Rated voltage (III/3): 150 V Rated surge voltage (III/3): 2.5 kV Rated voltage (III/2): 150 V Rated surge voltage (III/2): 2.5 kV Rated voltage (II/2): 250 V Rated surge voltage (II/2): 2.5 kV
Mounting	Mounting type: Wave soldering Pin layout: Linear pinning Connection method: Plug / solder connection
Material specifications	Material data - contact Note: WEEE/RoHS-compliant, free of whiskers according to IEC 60068-2-82/JEDEC JESD 201 Contact material: Cu alloy Surface characteristics: Tin-plated Metal surface terminal point (top layer): Tin (2 - 4 µm Sn) Metal surface terminal point (middle layer): Nickel (1.3 - 3 µm Ni) Metal surface contact area (top layer): Tin (2 - 4 µm Sn) Metal surface contact area (middle layer): Nickel (1.3 - 3 µm Ni) Metal surface soldering area (top layer): Tin (2 - 4 µm Sn) Metal surface soldering area (middle layer): Nickel (1.3 - 3 µm Ni) Material data - housing Color (Housing): light grey (7035) Insulating material: PA Insulating material group: I CTI according to IEC 60112: 600 Flammability rating according to UL 94: V0 Glow wire flammability index GWFI according to EN60695-2-12: 850 Glow wire ignition temperature GWIT according to EN60695-2-13: 775 Temperature for the ball pressure test according to EN60695-10-2: 125°C
Notes	Assembly instruction:: Refer to the data sheet for the range in the download area. General: Further information and detailed dimensions are available in the download area.
Dimensions	Dimensional drawing: https://dam-mdc.phoenixcontact.com/rendition/156443151564/2464924391ea904289a8463658d8e4b7/-S204x204-FJPG Pitch: 3.5 mm Width [w]: 20 mm Height [h]: 22.4 mm Length [l]: 20.22 mm Solder pin length [P]: 3.65 mm Pin dimensions: 0.8 x 0.8 mm PCB design Hole diameter: 1.2 mm
Mechanical tests	Visual inspection Specification: IEC 60512-1-1:2002-02 Result: Test passed Dimension check Specification: IEC 60512-1-2:2002-02 Result: Test passed Resistance of inscriptions Specification: IEC 60068-2-70:1995-12 Result: Test passed Polarization and coding Specification: IEC 60512-13-5:2006-02 Result: Test passed Contact holder in insert Specification: IEC 60512-15-1:2008-05 Contact holder in insert Requirements >20 N: Test passed Insertion and withdrawal forces Result: Test passed No. of cycles: 25 Insertion strength per pos. approx.: 7.2 N Withdraw strength per pos. approx.: 5.4 N
Electrical tests	Thermal test \| Test group C Specification: IEC 60512-5-1:2002-02 Tested number of positions: 5 Insulation resistance Specification: IEC 60512-3-1:2002-02 Insulation resistance, neighboring positions: > 3 TÃ© Air clearances and creepage distances \| Insulating material group: I Rated insulation voltage (III/3): 150 V Rated surge voltage (III/3): 2.5 kV Rated insulation voltage (III/2): 150 V Rated surge voltage (III/2): 2.5 kV Rated insulation voltage (II/2): 250 V Rated surge voltage (II/2): 2.5 kV
Environmental and real-life conditions	Vibration test Specification: IEC 60068-2-6:2007-12 Frequency: 10 - 150 - 10 Hz Sweep speed: 1octave/min 5g (60.1Hz...150Hz) Amplitude: 0.35mm (10Hz...60.1Hz) Test duration per axis: 2.5 h Durability test Specification: IEC 60512-9-1:2010-03 Impulse withstand voltage at sea level: 2.95 kV Contact resistance R₁: 1.76 mÃ© Contact resistance R₂: 1.82 mÃ© Insertion/withdrawal cycles: 25 Insulation resistance, neighboring positions: > 3 TÃ© Climatic test Specification: ISO6988:1985-02 Corrosive stress: 0.2 dm³SO₂on 300 dm³/40°C/1 cycle Thermal stress: 100°C/168h Power-frequency withstand voltage: 1.54 kV Ambient conditions Ambient temperature (operation): -40°C ... 105°C (dependent on the derating curve) Ambient temperature (storage/transport): -40°C ... 55°C Relative humidity (storage/transport): 30 % ... 70 % Ambient temperature (assembly): -5°C ... 100°C
Packaging specifications	Type of packaging: Box packaging Outer packaging type: Carton
