Notes | General: This item is also available with other cable lengths. For your specific requirements, please contact your local PHOENIX CONTACT subsidiary. |
Product properties | Product type: Assembled installation cable Product family: PRC 35 Number of positions: 5 Connection profile: 4+PE Coding: AD Insulation characteristics Protection class: II Degree of pollution: 2 |
Electrical properties | Rated voltage (III/2): 690 V Nominal voltage ATD: 690 V AC (III/2) in accordance with IEC 61984 600 V AC (III/2) In accordance with UL2238 500 V AC / DC (III/2) in accordance with IEC 61535, when mounted Rated surge voltage (III/2): 8 kV Rated current: 32 A (in accordance with IEC 61984) 25 A (in accordance with IEC 61535) |
Dimensions | Width: 37.6 mm Height: 37.6 mm Length: 2.5 m |
Material specifications | Color: black Color of the housing part: black Flammability rating according to UL 94: V0 Insulating material group: I / CTI 600 Seal material: EPDM Contact material: Cu Contact surface material: silver-plated Contact carrier material: PPE O-ring material: EPDM Material for screw connection: PPE Housing material: PPE |
Environmental and real-life conditions | Ambient conditions Ambient temperature (operation): 30°C ... 60°C Ambient temperature (storage/transport): 30°C ... 60°C Ambient temperature (assembly): 5°C ... 60°C |
Mounting | Connection method: Screw connection |
ECLASS | ECLASS-11.0: 27440109 ECLASS-12.0: 27440109 ECLASS-13.0: 27440109 |
ETIM | ETIM 9.0: EC003569 |
UNSPSC | UNSPSC 21.0: 39121400 |
