PHOENIX CONTACT 1209229
PHOENIX CONTACT 1209229
PHOENIX CONTACTNot available

ME-IO P 10U 7016 - Separating plate

DIN rail housing, Insulation plate, Housing cover, width: 2.89 mm, height: 112.2 mm, depth: 28.5 mm, color: anthracite gray (7016)
Product Code: 1209229
Partner cod.: 1209229
PHOENIX CONTACT


Diminuisci la quantità
Aumenta la quantità
Tecnichal data
Download
Tecnichal data
Product propertiesProduct type: Upper housing part
Type: Insulation plate
Housing type: DIN rail housing
Ventilation openings present: no
Housing series: ME-IO
DimensionsWidth: 2.89 mm
Height: 112.2 mm
Depth: 28.5 mm
Material specificationsColor: anthracite gray (7016)
Flammability rating according to UL 94: V0
CTI according to IEC 60112: 600
Surface characteristics: untreated
Housing material: Polyamide
Environmental and real-life conditionsAmbient conditions
Max. IP code to attain: IP20
Ambient temperature (operation): -40°C ... 105°C (depending on power dissipation)
Ambient temperature (storage/transport): -40°C ... 55°C
Ambient temperature (assembly): -5°C ... 100°C
Relative humidity (storage/transport): 80 %
MountingMounting type: Snap in
Mounting position: Vertical (horizontal DIN rail)
Packaging specificationsType of packaging: packed in cardboard
Outer packaging type: Carton
Download
PER SCARICARE I DOCUMENTI E' NECESSARIO EFFETTUARE L'ACCESSO AL SITO

Material_description_00001.pdf

Technical_drawing_10352.pdf
