1252173 PHOENIX CONTACT - Technology Bsa

HBUS8 107,6-8P-1S BK - DIN rail bus connectors

DIN rail connector, color: black, nominal current: 3 A (per contact), rated voltage (III/2): 100 V, number of positions: 8, product range: BC 107,6.., pitch: 2.54 mm, mounting: DIN rail mounting, locking: without

Product Code: 1252173 Copia - Copy

Partner cod.: 1252173 Copia - Copy

PHOENIX CONTACT

Product properties	Product type: DIN rail connector Product family: BC 107,6.. Number of positions: 8 Pitch: 2.54 mm Data management status Article revision: 01
Electrical properties	Nominal current I_N: 3 A (per contact) Contact resistance: 35.7 mÃ© Rated voltage (III/3): 60 V Rated surge voltage (III/3): 1.5 kV Rated voltage (III/2): 100 V Rated surge voltage (III/2): 1.5 kV Rated voltage (II/2): 150 V Rated surge voltage (II/2): 1.5 kV
Connection data	Maximum load current: 3 A
Material specifications	Material data - contact Contact material: Cu alloy Surface characteristics: Completely gold-plated Material data - housing Color (Housing): black (9005) Insulating material: PA Insulating material group: I CTI according to IEC 60112: 600 Flammability rating according to UL 94: V0 material specifications - connector Color (): ()
Dimensions	Pitch: 2.54 mm Width [w]: 111.23 mm Height [h]: 13.54 mm Length [l]: 36.82 mm
Mounting	Mounting type: DIN rail mounting
Mechanical tests	Visual inspection Specification: IEC 60512-1-1:2002-02 Result: Test passed Dimension check Specification: IEC 60512-1-2:2002-02 Result: Test passed
Environmental and real-life conditions	Vibration test Specification: IEC 60068-2-6:2007-12 Frequency: 10 - 150 - 10 Hz Sweep speed: 1 octave/min Amplitude: 0.15 mm (10 Hz ... 58.1 Hz) Acceleration: 20 m/s² Test duration per axis: 2.5 h Test directions: X-, Y- and Z-axis (pos. and neg.) Durability test Specification: IEC 60512-9-1:2010-03 Impulse withstand voltage at sea level: 1.75 kV Contact resistance R₁: 35.7 mÃ© Contact resistance R₂: 35.7 mÃ© Insertion/withdrawal cycles: 25 Climatic test Specification: DIN 50018:2013-05 Corrosive stress: 0.2 dm³SO₂on 300 dm³/40 °C/1 cycle Thermal stress: 100 °C/168 h Power-frequency withstand voltage: 0.84 kV Glow-wire test Specification: IEC 60695-2-10:2013-04 Temperature: 850 °C Time of exposure: 30 s Shocks Specification: IEC 60068-2-27:2008-02 Pulse shape: Semi-sinusoidal Acceleration: 150 m/s² Shock duration: 11 ms Test directions: X-, Y- and Z-axis (pos. and neg.) Ambient conditions Ambient temperature (operation): -40 °C ... 105 °C (dependent on the derating curve) Ambient temperature (storage/transport): -40 °C ... 55 °C Relative humidity (storage/transport): 80 % Ambient temperature (assembly): -5 °C ... 100 °C
Electrical tests	Air clearances and creepage distances \| Specification: IEC 60664-1:2007-04 Insulating material group: I Rated insulation voltage (III/3): 60 V Rated surge voltage (III/3): 1.5 kV minimum clearance value - non-homogenous field (III/3): 0.8 mm minimum creepage distance (III/3): 1.6 mm Rated insulation voltage (III/2): 100 V Rated surge voltage (III/2): 1.5 kV minimum clearance value - non-homogenous field (III/2): 0.5 mm minimum creepage distance (III/2): 0.71 mm Rated insulation voltage (II/2): 150 V Rated surge voltage (II/2): 1.5 kV minimum clearance value - non-homogenous field (II/2): 0.5 mm minimum creepage distance (II/2): 0.8 mm
Packaging specifications	Outer packaging type: Carton
