| Product properties | Product type: Panel PC Computer data Processor: Intelî Celeronî N3350 Operating system: Windowsî 10 IoT Enterprise LTSC 2019 (64-bit), Multi-language Cooling: passive RAM: 4 GB DDR3 SODIMM Data storage system: 128 GB mSATA Display Display type: 25.7 cm / 10.1" TFT Screen resolution: 1024ÃxÃ600ÃPixel(s)Ã(WVGA) Touch technology: projective-capacitive (PCAP) Display lighting type: LED Brightness: 300 cd/m², typical (adjustable) MTBF: > 25000 h Color spectrum: 262000Ãcolors Reading angle bottom: 10-point touch |
| System properties | User software: without user software |
| Electrical properties | Service life of battery: 5 years (typical) Supply Power supply unit: 24 V DC ñ20 % Max. current consumption: 1.09 A Real-time clock Realtime clock: Yes (battery-backed) |
| Connection data | Connection method: Screw connection Conductor cross section, rigid: 0.14 mm² ... 1.5 mm² Conductor cross section, flexible: 0.14 mm² ... 1.5 mm² Conductor cross section AWG: 28 ... 16 Stripping length: 7 mm |
| Interfaces | Interfaces: 1x COM (RS-232) 1x USB 2.0 2x USB 3.0 2x COM (RS-232/422/485) Monitor output: 1x HDMI Network: 2x Ethernet (10/100/1000 Mbps), RJ45 LAN chipset: Intelî I210-AT |
| Dimensions | External dimensions Width / Height / Depth: 266 mm / 184 mm / 48 mm Installation dimensions Width / Height / Installation depth: 229 mm / 155 mm / (Panel cutout for 10" display) |
| Environmental and real-life conditions | Ambient conditions Degree of protection: IP65 (front), IP20 (back) Ambient temperature (operation): -5°C ... 50°C Ambient temperature (storage/transport): -20°C ... 70°C Permissible humidity (operation): 10 % ... 90 % (non-condensing) Permissible humidity (storage/transport): 10 % ... 90 % (non-condensing) Shock: 20g, 11 ms in accordance with IEC 60068-2-27 Vibration (operation): DINÃENÃ60068-2-6 |
| Mounting | Mounting type: Front mounting VESA holder (not for industrial use) Holder system: VESA MIS-D 75 VESA MIS-D 100 C |
