1335856 PHOENIX CONTACT - Technology Bsa

BC 71,6 DKL R D2,4 TCG BK - Housing cover with touch display

DIN rail housing for use in distribution boards in accordance with DIN 43880, Latching cover (non-detachable), integrated capacitive 2.4" touch display,resolution:320x240Pixel(s),interface:4-wire SPI, width: 71.6 mm, height: 45 mm, depth: 13.5 mm, color: black (9005)

Product Code: 1335856 Copia - Copy

Partner cod.: 1335856 Copia - Copy

PHOENIX CONTACT

Notes	General: Refer to the data sheet for the range in the download area.
Product properties	Product type: Cover Product family: BC 71,6 Type: Latching cover (non-detachable), integrated capacitive 2.4" touch display Housing type: DIN rail housing for use in distribution boards in accordance with DIN 43880 Ventilation openings present: no Housing series: BC Display Display type: TFT, IPS capacitive Diagonal: 2.4 in. / 6.1 cm (Display) Screen resolution: 320ÃxÃ240ÃPixel(s)Ã(QVGA) Display formats: 3:4 Display lighting type: LED, white Controller: GT911 (Goodix)
Interfaces	Interface: 4-wire SPI
Dimensions	Width: 71.6 mm Height: 45 mm Depth: 13.5 mm
Material specifications	Color: black (9005) Flammability rating according to UL 94: V0 CTI according to IEC 60112: 600 Surface characteristics: untreated Housing material: Polycarbonate
Environmental and real-life conditions	Vibration test Specification: IEC 60068-2-6:2007-12 Frequency: 10 - 150 - 10 Hz Sweep speed: 1Ãoctave/min Amplitude: 0.15Ãmm (10ÃHzÃ...Ã58.1ÃHz) Acceleration: 2g (58.1ÃHzÃ...Ã150ÃHz) Test duration per axis: 2.5 h Test directions: X-, Y- and Z-axis Glow-wire test Specification: IEC 60695-2-11:2014-02 Temperature: 850°C Time of exposure: 30 s Mechanical strength / tumbling barrel Specification: IEC 60068-2-31:2008-05 Height of fall: 50Ãcm Frequency: 50 Shocks Specification: IEC 60068-2-27:2008-02 Pulse shape: Half-sine Acceleration: 15g Shock duration: 11Ãms Number of shocks per direction: 3 Test directions: X-, Y- and Z-axis (pos. and neg.) Degree of protection (IP code) Specification: IEC 60529:1989-11 + AMDÃ1:1999-11 + AMDÃ2:2013-08 Ambient conditions Max. IP code to attain: IP20 Ambient temperature (operation): -20°C ... 70°C Ambient temperature (storage/transport): -30°C ... 70°C
Mounting	Mounting type: Latching with upper housing part Mounting position: Vertical (horizontal DIN rail)
