Product properties | Product type: Cable by the meter Number of positions: 12 Application: Connector Shielded: yes |
Cable/line | Cable length: 100 m Black PUR/PVC twisted pair[35T] Dimensional drawing: https://dam-mdc.phoenixcontact.com/rendition/156443151564/97f04793c00c884ea3682368c5f96ea1/-S204x204-FJPG Cable weight: 87 kg/km UL AWM Style: 20233 / 1061 (80°C/300 V) Number of positions: 12 Shielded: yes Cable type: Black PUR/PVC twisted pair[35T] Conductor structure signal line: 18x 0.10 mm AWG signal line: 26 Conductor cross section: 12x 0.14 mm² (Signal line) Wire diameter incl. insulation: 1 mm ±0.05 mm (Signal line) External cable diameter: 8.5 mm ±0.2mm Outer sheath, material: PUR External sheath, color: black RAL9005 Conductor material: Tin-plated Cu litz wires Material wire insulation: PVC Single wire, color: white-brown, green-yellow, gray-pink, blue-red, black-violet, gray/pink-red/blue Twisted pairs: 2 cores to the pair Overall twist: Six pairs around the filler to the core Optical shield covering: 85 % Max. conductor resistance: ⤠142 é/km (at 20°C) Insulation resistance: ⥠10 Mé*km (at 20°C) Nominal voltage, cable: 42 VAC Test voltage: 1500 VAC Minimum bending radius, fixed installation: 5 x D Minimum bending radius, flexible installation: 10 x D Max. bending cycles: 2000000 Flame resistance: According to DINEN60332-1-2 According to VW-1 Resistance to oil: in accordance with DINEN60811-2-1 Other resistance: hydrolysis and microbe resistant in accordance with EN50396 Special properties: Flexible cable conduit capable Ambient temperature (operation): -40°C ... 80°C (cable, fixed installation) -5°C ... 80°C (Cable, flexible installation) |
ECLASS | ECLASS-11.0: 27061801 ECLASS-12.0: 27061801 ECLASS-13.0: 27061801 |
ETIM | ETIM 9.0: EC003249 |
UNSPSC | UNSPSC 21.0: 26121600 |
