| Notes | General: For contact inserts HC-B16, BB32, D40, DD72, HS6, HV6, M, K, HV06-I-PR, HV 6-E...C |
| Product properties | Type: B16 Product type: Housing with locking latch Product family: HC-EVO-B Application: Standard No. of cable outlets: 2 Type of the screw connection: 2x M40 Housing type: Box mounting bases Cable outlet: lateral Pg screw connection: none |
| Dimensions | Dimensional drawing: https://dam-mdc.phoenixcontact.com/rendition/156443151564/c2f81f54ae9d5f42a404193dc0993d9e/-S204x204-FJPG Width: 57 mm Height: 84 mm Length: 117 mm Hole diameter: 5.5 mm |
| Material specifications | Flammability rating according to UL 94: V0 (Housing) V0 (Interlock) Seal material: NBR Locking latch material: PA Impact strength: IK09 Housing material: PA |
| Mechanical properties | Mechanical data Type of the screw connection: 2x M40 Locking type: Latch |
| Mounting | Assembly instructions: One of the two openings for the screw connections is sealed but can be broken open using a screwdriver. |
| Environmental and real-life conditions | Ambient conditions Degree of protection: IP66 Enclosure rating (NEMA): 12 (UL50e) Impact strength: IK09 Ambient temperature (operation): -40°C ... 125°C |
| ECLASS | ECLASS-11.0: 27440202 ECLASS-12.0: 27440202 ECLASS-13.0: 27440202 |
| ETIM | ETIM 9.0: EC000437 |
| UNSPSC | UNSPSC 21.0: 31261500 |
