A-EXB-25-66L-N-S - Pressure compensation element
![](https://www.technologybsa.com/wp-content/uploads/2023/08/copia.png)
![](https://www.technologybsa.com/wp-content/uploads/2023/08/copia.png)
Product properties | Product type: Pressure compensation element Application: Ex Manufacturer: CMP Manufacturer Designation: 781 M25(M) N.PLTD BREATH/DRAIN PLUG Manufacturer product number: 781EM35 Air flow rate: 48l/min (at 1ýbar) |
Connection data | Tightening torque: 10 Nm (Installation torque) |
Ex data | Suited for EX-applications: yes |
Dimensions | Dimensional drawing: https://dam-mdc.phoenixcontact.com/rendition/156443151564/202a085d72969d439a6862fd43a41f86/-S204x204-FJPG Length: 32 mm Length of the connecting thread: 15 mm Length without connecting thread: 17 mm Diameter: 25 mm Connecting thread diameter: 25 mm Wrench size, union nut: 31.5 mm Hexagon angular dimension: 39.6 mm Thread type connection side: M25 x 1.5 Thread pitch: 1.5 mm |
Material specifications | Color: Brass Material: Brass, nickel-plated Seal material O-ring: Silicon |
Environmental and real-life conditions | Ambient conditions Degree of protection: IP66 Ambient temperature (operation): -60°C ... 130°C |
Approvals | ATEX: Sira 10ATEX1307U 781D: Ex II 2 GD Exd IIC Gb, Ex ta IIIC Da, 781E: Ex II 2 GD Exe IIC Gb, Ex ta IIIC Da IECEx: IECEx SIR 10.0149U 781D: Ex d IIC Gb, Ex ta IIIC Da 781E: Ex e IIC Gb, Ex ta IIIC Da |
Standards and regulations | IEC Ex Standards/specifications: IEC 60079-0, -1, -7, -31 EN Ex Standards/specifications: EN60079-0, -1, -7, -31 |
Mounting | Assembly instructions: Mount at the lowest point of the housing, including ribbed counter nut (ensure correct orientation when mounting, the grooved side must be pointing towards the wall) |
ECLASS | ECLASS-11.0: 27440192 ECLASS-12.0: 27440192 ECLASS-13.0: 27440192 |
ETIM | ETIM 9.0: EC002943 |
UNSPSC | UNSPSC 21.0: 39121400 |
