A-INL-NPT3/4-P-GY - Counter nut
![](https://www.technologybsa.com/wp-content/uploads/2023/08/copia.png)
![](https://www.technologybsa.com/wp-content/uploads/2023/08/copia.png)
Product properties | Product type: Flat nut Thread type: 3/4"-NPT |
Dimensions | Dimensional drawing: https://dam-mdc.phoenixcontact.com/rendition/156443151564/69687f05d25f364e96424388eea334cb/-S204x204-FJPG Length: 5 mm Diameter: 25.9 mm Connecting thread diameter: 25.9 mm Wrench size, counter nut: 33 mm Hexagon angular dimension: 37.5 mm Thread type connection side: 3/4"-NPT |
Material specifications | Material: PA Flammability rating according to UL 94: V2 |
Cable/line | Halogen-free: yes |
Environmental and real-life conditions | Ambient conditions Ambient temperature (operation): -40°C ... 100°C |
ECLASS | ECLASS-11.0: 27144424 ECLASS-13.0: 27140807 |
ETIM | ETIM 9.0: EC000940 |
UNSPSC | UNSPSC 21.0: 31161700 |
