PHOENIX CONTACT 1411269
PHOENIX CONTACTNot available

A-INLE-M20-N-S - EMC nut

EMC nut, for threads M20 x 1.5, color: silver
Product Code: 1411269
Partner cod.: 1411269
PHOENIX CONTACT


Diminuisci la quantità
Aumenta la quantità
Tecnichal data
Technical Specs
Description
Download
Tecnichal data
Product propertiesProduct type: Flat nut
Thread type: M20
DimensionsDimensional drawing: https://dam-mdc.phoenixcontact.com/rendition/156443151564/c0f9ab480349204eb1333f2ed122bcb0/-S204x204-FJPG
Length: 4.7 mm
Diameter: 20 mm
Connecting thread diameter: 20 mm
Wrench size, counter nut: 24 mm
Hexagon angular dimension: 27 mm
Thread type connection side: M20 x 1.5
Thread pitch: 1.5 mm
Material specificationsMaterial: Brass, nickel-plated
Cable/lineHalogen-free: yes
Environmental and real-life conditionsAmbient conditions
Ambient temperature (operation): -70°C ... 220°C
MountingAssembly instructions: for EMC cable glands, for removing a non-conductive surface coating
Technical Specs
ECLASSECLASS-11.0: 27144424
ECLASS-13.0: 27140807
ETIMETIM 9.0: EC000940
UNSPSCUNSPSC 21.0: 31161700
Description
EMV nut, material: Brass, nickel-plated, for threads M20 x 1.5, color: silver
Download
PER SCARICARE I DOCUMENTI E' NECESSARIO EFFETTUARE L'ACCESSO AL SITO

Manufacturer_declaration_07511.pdf

Technical_drawing_13194.pdf
