| Product properties | Product type: Full screw connection Application: Ex No. of conductors: 1 Manufacturer: WISKA Manufacturer Designation: EMSKE-L 32 Shielded: no |
| Ex data | Cable types that can be used: for unarmored cables Suited for EX-applications: yes |
| Dimensions | Dimensional drawing: https://dam-mdc.phoenixcontact.com/rendition/156443151564/c7fed197d05f59469543195dc4c399b6/-S204x204-FJPG Length: 43 mm Length of the connecting thread: 15 mm Hole diameter: 32.1 mm ... 32.3 mm Wrench size, union nut: 36 mm Wrench size, support: 36 mm Hexagon angular dimension: 40 mm Thread type connection side: M32 x 1.5 Thread pitch: 1.5 mm |
| Connection data | Tightening torque: 20 Nm (Support sleeve) |
| Material specifications | Color: Brass Material: PA Seal material Cable seal: EPDM Material for screw connection: Brass, nickel-plated |
| Cable/line | External cable diameter (): 13 mm ... 21 mm Tightening torque, union nut: 20.00 Nm |
| Environmental and real-life conditions | Ambient conditions Degree of protection: IP66 IP68 (5Ãbar / 0.5Ãh) Ambient temperature (operation): -40°C ... 75°C (static) |
| Approvals | ATEX: II 2 G/D EEx e II IP68 IECEx: Ex e IIC Gb, Ex tb IIIC Db |
